Schneider Electric

Schneider XPSAPF5342 Safety Modules

SKU XPSAPF5342

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Schneider Electric
  • Product No.: XPSAPF5342
  • Origin France
  • Product Type: Safety Modules
  • Payment: T/T, Western Union
  • Weight: 0.4 kg
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

Electrics Safety Modules
Quantità
Call sales Contact

Product Description

Description

The XPSAPF5342 is an XPS-AP safety module engineered by Schneider Electric for emergency stop and safety monitoring applications in industrial environments. This specialized unit operates on a 48 V AC/DC supply voltage and is designed to maintain system integrity and compliance with machine safety standards. The robust construction ensures dependable performance in demanding manufacturing settings, supporting routine functional testing to verify safety loop reliability. Typical industrial applications include emergency stop circuits for automated production lines, machinery safeguarding, and process control safety interlocks. It is fully compatible with standard industrial safety relay architectures and control cabinet layouts.

Features

  • XPS-AP safety module designed for emergency stop and safety monitoring systems
  • Operates on a reliable 48 V AC/DC power supply rating
  • Built-in testability features to support routine compliance and safety checks
  • Robust industrial enclosure for control cabinet installation

Applications

  • Emergency stop monitoring for automated machinery and assembly lines
  • Industrial production equipment safety interlock systems
  • Factory floor safety circuit control and supervision

Technical Specifications

Technical Parameter Specification
Brand Schneider Electric
Manufacturer Schneider Electric
Range XPS-AP
Type of product Safety modules
Application Emergency stop
Supply Voltage 48 V AC/DC
Product phase Phase-Out
Weight 0.40 kg
Commodity Code 85371091

Installation Guidelines

  • Mount the safety module securely onto a standard DIN rail inside an appropriate industrial control cabinet maintaining required enclosure protection ratings.
  • Connect the 48 V AC/DC supply voltage lines to the designated power terminals ensuring proper fusing and circuit protection.
  • Wire emergency stop pushbuttons and safety interlock contacts to the module inputs in accordance with relevant safety category requirements.
  • Verify proper operation of the safety outputs and test the emergency stop circuit functionality prior to system commissioning.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What is the primary function of the XPSAPF5342 module?
It is an XPS-AP safety module designed specifically for emergency stop applications and safety circuit monitoring in industrial automation.
What power supply voltage does this safety module require?
The module operates on a 48 V AC/DC supply voltage.
Does the unit support routine functional testing?
Yes, the module is testable to support regular checks that maintain system integrity and safety standard compliance.
