Schneider Zelio Logic SR3XT101B Discrete I/O Expansion Module

SKU SR3XT101B

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Schneider Electric
  • Product No.: SR3XT101B
  • Origin France
  • Product Type: Logic Modules
  • Payment: T/T, Western Union
  • Weight: 0.18 kg
  • Dimensions: 10cm x 9cm x 6,8cm
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

Logic Modules Zelio Logic
Quantità
Call sales Contact

Product Description

Description

The SR3XT101B is a Zelio Logic discrete I/O expansion module engineered to extend the input/output capacity of Zelio Logic smart relays. This module provides 10 additional I/O channels and operates on a 24 V AC supply. It is designed for easy snap-on integration with the base controller, allowing for scalable control solutions in small-scale automation projects where simplicity and reliable I/O handling are required.

Features

  • 10 discrete I/O channels
  • 24 V AC operating voltage
  • Compact footprint for DIN rail mounting
  • Seamless compatibility with Zelio Logic smart relay systems
  • Ideal for expanding control logic in localized automation tasks

Applications

  • Building automation and lighting control
  • Small machinery sequencing
  • HVAC system control interfaces
  • Simple process monitoring
  • Conveyor system management

Technical Specifications

Specification Details
Manufacturer Schneider Electric
Product Type Logic modules
I/O Capacity 10 I/O
Operating Voltage 24 V AC
Dimensions 10 x 9 x 6.8 cm
Weight 0.18 kg
Commodity Code 85371099
Product Status Active

Installation Guidelines

  • Mounting: Mount the module on a standard 35 mm DIN rail or directly onto a panel using the integrated mounting clips.
  • Connection: Ensure a secure connection to the Zelio Logic base relay using the provided expansion interface connector.
  • Wiring: Connect I/O devices according to the terminal diagram. Ensure the 24 V AC power supply matches the module’s voltage rating to avoid electrical damage.
  • Environment: Install within a protected electrical enclosure to prevent exposure to dust, moisture, or corrosive industrial vapors.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What is the primary purpose of the SR3XT101B module?
It acts as a discrete I/O expansion module to increase the input and output capacity of a Zelio Logic smart relay system.
What is the supply voltage for this expansion module?
The module operates on a 24 V AC supply.
How many I/O channels does this unit provide?
The module provides 10 discrete I/O channels.
Is the SR3XT101B currently supported by the manufacturer?
Yes, the module is currently listed with an Active product lifecycle status.
