Siemens 6ES7157-0AA82-0XA0 SIMATIC DP IM157 Interface Module

SKU 6ES7157-0AA82-0XA0

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: Siemens
Product No.: 6ES7157-0AA82-0XA0
Origin Germany
Product Type: Interface Module
Barcode: 85176200
Payment: T/T, Western Union
Weight: 0.29 kg
Dimensions: 4.00 cm x 12.50 cm x 13.00 cm
Shipping port: Xiamen
Warranty: 12 months

Product Description

Description

The Siemens 6ES7157-0AA82-0XA0 is a SIMATIC DP IM157 interface module designed to create a seamless link between PROFIBUS DP and PROFIBUS PA fieldbus networks. This module operates as a DPV1 slave on the PROFIBUS DP segment and, when combined with one or more DP/PA couplers, forms a complete DP/PA Link. Engineered for an extended temperature range, it provides reliable performance in demanding industrial environments, ensuring robust data exchange for process control applications. Its compatibility with the SIMATIC system facilitates integration into existing automation architectures.

Features

Provides a communication interface between PROFIBUS DP and PROFIBUS PA networks.
Functions as a DPV1 slave on the PROFIBUS DP master system.
Forms a DP/PA Link in conjunction with external DP/PA couplers.
Specified for operation over an extended temperature range.
Integrates with the Siemens SIMATIC automation family.

Applications

Process automation and control systems
Chemical and pharmaceutical manufacturing
Oil and gas processing facilities
Water and wastewater treatment plants
Power generation and distribution

Technical Specifications

Specification	Value
Manufacturer	Siemens
Product Series	SIMATIC DP
Model Number	6ES7157-0AA82-0XA0
Product Type	IM157 Interface Module (DP/PA Link)
PROFIBUS DP Function	DPV1 Slave
Operating Environment	Extended Temperature Range
Product Lifecycle Status	Obsolete
Shipping Weight	0.29 kg
Package Dimensions	4.00 cm x 12.50 cm x 13.00 cm
Commodity Code	85176200
ECCN	N
Country of Origin	Germany (Estimate)

Installation Guidelines

CRITICAL WARNING: Electrical hazard. Installation must be performed by qualified personnel only. De-energize all power sources and follow Lockout/Tagout (LOTO) procedures before handling, installing, or servicing this equipment. Failure to comply can result in severe injury or death.

1 Verify all power to the control panel or cabinet is disconnected and locked out.
2 Securely mount the IM157 module onto the designated standard DIN rail within the enclosure, ensuring proper clearance for ventilation and wiring.
3 Connect the incoming PROFIBUS DP cable to the appropriate terminals on the module. Ensure the cable shield is properly terminated at one end to a low-impedance ground point to minimize noise.
4 Connect the module to the associated DP/PA coupler(s) using the specified cabling. Maintain signal integrity by adhering to maximum cable length and routing guidelines.
5 Connect the 24 VDC power supply to the designated terminals, observing correct polarity.
6 After verifying all connections, remove the LOTO device and re-energize the system. Commission the module according to project-specific network configuration procedures.

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

What is the primary function of the 6ES7157-0AA82-0XA0 module?

Its primary function is to act as an interface, or link, between a PROFIBUS DP master system and a PROFIBUS PA field device network.

What role does this module play on the PROFIBUS DP network?

The module operates as a DPV1 slave on the PROFIBUS DP network, responding to commands from the DP master.

Is this module suitable for harsh industrial environments?

Yes, it is specifically designed for an extended temperature range, making it suitable for demanding industrial applications.

What is required to create a complete DP/PA Link with this module?

To form a complete DP/PA Link, the 6ES7157-0AA82-0XA0 interface module must be used in conjunction with one or more DP/PA couplers.

What is the product lifecycle status of this module?

According to the provided information, this product is classified as Obsolete, meaning it is no longer in active production by the manufacturer.
