Description

This module is a Siemens 6ES7488-3AA00-0AB0 central processing unit, designated as the CPU488-3 for the SIMATIC M7-400 series. It is engineered for demanding industrial automation applications, featuring a Pentium 120 MHz processor to manage complex control tasks reliably. The unit includes an integrated MPI interface for communication within the automation system and provides two interface module positions for flexible system expansion and connectivity.

Features

• Equipped with a Pentium 120 MHz processor.
• Integrated Multi-Point Interface (MPI) for network communication.
• Features two positions for optional interface (IF) modules.
• Designed for continuous operation in critical production environments.
• Part of the robust SIMATIC M7-400 automation platform.

Applications

• Process control systems in manufacturing facilities.
• High-speed machine automation and sequencing.
• Data acquisition and control for industrial plants.
• Complex logic and motion control applications.

Technical Specifications

Installation Guidelines

1. 1
   De-energize System: Before installation, ensure all power to the PLC rack or chassis is disconnected and locked out according to standard safety procedures (LOTO). Verify absence of voltage.
2. 2
   Position the Module: Identify the designated CPU slot in the SIMATIC M7-400 rack. Align the module's backplane connector with the corresponding connector on the rack's backplane.
3. 3
   Seat the Module: Apply firm, even pressure to slide the module into the slot until it is fully seated. The module should click into place, indicating a secure connection.
4. 4
   Secure the Module: Tighten the retaining screw(s) on the front panel of the CPU to secure it firmly to the chassis. Do not overtighten.
5. 5
   Connect Interfaces: Connect the MPI communication cable and any other required interface module cables to the appropriate ports on the front of the CPU. Ensure all connections are secure.
