The 6ES7650-1AH61-5XX0 is a SIMATIC PCS7 redundant F-AI6 MTA interface module engineered for high-availability process automation and safety-instrumented systems. This interface module is designed for the redundant connection of the ET200M F-AI6 HART module (6ES7336-4GE00-0AB0), providing 6 channels with individual fusing and a redundant power supply featuring integrated fusing and status LED displays. It supports a measuring range of 0/4-20 mA. When deployed in combination with the alternative F-AI module 6ES7336-1HE00-0AB0, two additional FET adapters (6ES7650-1BD51-0XX0) are required. Typical industrial applications include safety instrumented functions (SIS), emergency shutdown systems, chemical plants, oil and gas refineries, and power generation facilities requiring fault-tolerant analog input processing. It is fully compatible with Siemens SIMATIC PCS7 distributed control systems and ET200M automation architectures.

Features

  • SIMATIC PCS7 redundant F-AI6 MTA interface module for high-availability safety systems
  • Designed for redundant connection of ET200M F-AI6 HART modules (6ES7336-4GE00-0AB0)
  • 6 input channels with individual fusing and redundant power supply with built-in fusing
  • Integrated LED status displays for operational and fault diagnostics
  • Supports standard process measuring ranges of 0/4-20 mA

Applications

  • Safety Instrumented Systems (SIS) and Emergency Shutdown (ESD) loops
  • Chemical, petrochemical, and refinery process control networks
  • Power generation and critical industrial automation infrastructure
  • Fault-tolerant analog measurement signal acquisition

Technical Specifications

Technical Parameter Specification
Brand Siemens
Manufacturer Siemens
Range SIMATIC
Type of product Interface modules
Product phase Obsolete
System Family SIMATIC PCS7
Module Type Redundant F-AI6 MTA Interface Module
Supported F-AI Module 6ES7336-4GE00-0AB0 (or 6ES7336-1HE00-0AB0 with 2x 6ES7650-1BD51-0XX0 adapters)
Number of Channels 6 channels
Channel Protection Individually fused
Power Supply Redundant power supply with fusing
Measuring Range 0/4-20 mA
Diagnostics LED displays
Dimensions 25.40 x 13.60 x 8.60 cm
Weight 0.55 kg
Commodity Code 85389091
Export Control Regulations (ECCN) EAR99

Installation Guidelines

  • Mount the interface module securely onto a standard mounting rail or designated termination assembly plate within the safety control cabinet.
  • Establish redundant 24V DC power supply connections to the fused dual power inputs, verifying proper polarity before energizing.
  • Connect the field signal wiring to the 6-channel analog inputs, ensuring individual loop fusing and signal shielding practices are observed.
  • Plug in the corresponding ET200M F-AI6 HART module connection cables and verify LED status indicators during system startup.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What is the primary application of the 6ES7650-1AH61-5XX0 interface module?
It is designed for SIMATIC PCS7 systems to provide redundant connection for ET200M F-AI6 HART modules in safety-instrumented process applications.
How many channels does the module support and what is the measuring range?
The module supports 6 channels with individual fusing and a measuring range of 0/4-20 mA.
Are additional components required if using alternative F-AI modules?
Yes, when used in combination with the F-AI module 6ES7336-1HE00-0AB0, two FET adapters (6ES7650-1BD51-0XX0) are additionally required.
