Description

The Siemens 6ES7718-1BB01-1BC2 is a SIMATIC Field PG M6 Advanced, a ruggedized portable device designed for industrial automation engineering, commissioning, and maintenance tasks. This high-performance unit is equipped with an Intel i7-8850H 6-core processor, 16 GB of DDR4 RAM, and a dual-drive storage configuration featuring a 512 GB SATA SSD and a 512 GB NVMe SSD for rapid data access and application performance. It includes a 15.6-inch Full HD display and comes pre-loaded with a comprehensive suite of Siemens TIA Portal V17 engineering software, including licenses for STEP 7 Professional, WinCC Advanced, and Safety Advanced. This specific configuration features an AZERTY (French) keyboard and a European power cord, and is supplied without legacy S5 interfaces.

Features

• High-performance Intel i7-8850H 6-core processor with Hyper-Threading.
• 16 GB DDR4 SO-DIMM memory for demanding engineering applications.
• Dual solid-state drive configuration for optimized storage and speed.
• Integrated 15.6-inch Full HD (1920x1080) non-glare display.
• Built-in WLAN 802.11ac and Bluetooth v5.0 for wireless connectivity.
• Includes DVD+/-RW optical drive for legacy media access.
• Pre-installed with Windows 10 IoT Enterprise 2019 LTSC (64-bit).
• Comes with V17 Combo licenses for STEP 7 Professional, WinCC Advanced, and Safety Advanced.

Applications

• Programming and configuration of SIMATIC S7 PLCs and SIMATIC HMI panels.
• On-site commissioning and startup of industrial machinery and production lines.
• Plant-floor diagnostics, troubleshooting, and system maintenance.
• Mobile engineering workstation for control system development and testing.
• Service and support for automation systems in manufacturing, process control, and infrastructure.

Technical Specifications

Installation and Handling Guidelines

1. 1
   Initial Setup: Upon first use, connect the provided power adapter and allow the device to fully charge. Follow the on-screen prompts to complete the initial Windows operating system setup and user account creation.
2. 2
   Software Activation: The pre-installed Siemens software requires license activation. Use the included license keys and the Automation License Manager utility to transfer and activate the necessary licenses for STEP 7, WinCC, and Safety.
3. 3
   Network Configuration: Configure network settings (Ethernet or WLAN) to match the automation network requirements. Ensure IP addresses, subnet masks, and gateway settings are correct to establish communication with PLCs and other devices.
4. 4
   Safe Handling: Although ruggedized, transport the Field PG in a suitable carrying case to protect it from impact and environmental hazards. Keep all interface ports covered when not in use to prevent ingress of dust and moisture.
5. 5
   Grounding: When connecting to industrial equipment, ensure a proper grounding connection is established through the communication cable shield or a dedicated grounding point to prevent electrostatic discharge (ESD) damage and ensure signal integrity.
