Designed to facilitate alternative mounting configurations, the Weidmuller 1504440000 (Type: IE-WALLMOUNT-KIT-46MM) provides a rugged mechanical solution for direct wall-mounting of standard DIN rail-based Industrial Ethernet switches and modules. This kit allows field engineers to bypass traditional TS35 DIN rail requirements, enabling secure installation of active and passive communication hardware directly onto machine frames, control cabinet walls, or flat structural surfaces.
| Part Number | Type Designation | Description | Compatible Width |
|---|---|---|---|
| 1504440000 | IE-WALLMOUNT-KIT-46MM | Wall mounting kit for Industrial Ethernet components | 46 mm |
| Parameter | Specification Value |
|---|---|
| Manufacturer | Weidmuller |
| Part Number | 1504440000 |
| Type | IE-WALLMOUNT-KIT-46MM |
| Function | Mounting kit for alternative wall-mounting of DIN rail-based components |
| Compatible Device Width | 46 mm |
| Net Weight | 29 g |
| Shipping Weight (Calculated) | 0.25 kg |
| Environmental Compliance | RoHS Conform |
This mounting kit is specifically engineered for Weidmuller active switches and passive modules with a housing width of exactly 46 mm. Before deployment, verify that the physical footprint, screw-hole alignment, and depth of your specific switch model match the mounting bracket dimensions to ensure a flush, secure fit.
When mounting active Ethernet switches flat against a wall or machine panel using the IE-WALLMOUNT-KIT-46MM, natural convection airflow is altered compared to standard vertical DIN rail mounting. System designers must ensure that the ambient temperature of the mounting surface and surrounding air does not exceed the maximum operating temperature of the active device, as heat dissipation efficiency may be slightly reduced without the standard DIN rail air gap.
To maintain proper electromagnetic compatibility (EMC) and functional grounding, ensure that the mounting screws make direct, paint-free contact with both the metal chassis of the switch and the grounded mounting surface. If mounting to a painted or non-conductive surface, run a dedicated functional earth (FE) strap from the switch ground terminal to the local ground busbar.
CRITICAL WARNING
Before installing or servicing any active network components, ensure all power supplies feeding the device are completely de-energized. Failure to isolate power prior to mechanical installation can result in equipment damage or unexpected electrical discharge.
Align the wall-mounting brackets with the pre-drilled mounting holes on the rear of the 46mm Weidmuller device.
Secure the brackets to the device chassis using the recommended OEM screws, tightening to the specified torque rating to prevent thread damage.
Position the assembled unit against the flat mounting surface, mark the pilot holes, and secure the assembly using appropriate heavy-duty fasteners suitable for the wall material.
Verify mechanical rigidity and establish the functional ground connection before re-applying power to the device.
