Yokogawa AIP830-111/EIM CENTUM VP Operation Keyboard

SKU AIP830-111/EIM

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: Yokogawa
Product No.: AIP830-111/EIM
Origin Japan
Product Type: Operation Keyboard
Payment: T/T, Western Union
Weight: 2.0 kg
Dimensions: 500 mm x 225 mm x 44 mm (W x H x D)
Shipping port: Xiamen
Warranty: 12 months

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

Quantità

Call sales Contact

Product Description

Description

The Yokogawa AIP830-111/EIM is an operation keyboard for single-loop operation designed for Desktop Type Human Interface Stations (HIS) in CENTUM VP systems. This flat keyboard features alphanumeric keys, special control keys, window call keys, and 64 user-definable function keys used for process control and plant monitoring. Communication and power delivery are established via dual USB type A interfaces, utilizing USB 2.0 full-speed for operation keyboard functions and USB 1.1 full-speed for the independent integrated USB speaker sound function. Equipped with a Mode selection switch and Type B operation confirmation keys, the hardware maintains compliance with IEC 61010-1 installation category Class I.

Features

Dual USB A-type PC interface connections for bus-powered data and audio transmission
Integrated independent USB speaker sound function alongside an electronic buzzer
Includes physical Mode selection switch and Type B operation confirmation keys
64 user-definable function keys assigned to plant monitoring and control operations
English instruction manual option included (/EIM)

Applications

Yokogawa CENTUM VP Desktop Type Human Interface Station (HIS) operation
Plant monitoring, process control, and alarm acknowledgement interface

Ordering Information

Model / Option Code	Suffix Code	Option Code	Description
AIP830			Operation Keyboard for Single-loop Operation
Mode selection switch	-0		Without Mode selection switch
	-1		With Mode selection switch
Operation confirmation key		0	Operation confirmation key Type A
		1	Operation confirmation key Type B
Always 1		1	Always 1
Option Codes		/VESA	With VESA Bracket
		/EIM	With English Instruction Manual
		/JIM	With Japanese Instruction Manual

Technical Specifications

Category	Parameter	Specification
General Specifications	Manufacturer	Yokogawa Electric Corporation
	Keyboard Type	Flat keyboard
	Chassis Color	Black (Equivalent to Munsell No. N1.5)
	IEC Classification	IEC 61010-1 Installation Category Class I
Electrical	Input Voltage	5 V DC +/- 5% (Supplied from USB Port of PC)
	Maximum Consumption Current	1 A
Communication & Audio	PC Interface Connectors	USB A type x 2
	Operation Keyboard Protocol	USB 2.0 (Full-speed, Bus-powered)
	Sound Function Protocol	USB 1.1 (Full-speed, Bus-powered)
	Sound Output	Built-in USB speaker and Electronic buzzer
Environmental	Operating Ambient Temperature	5 to 40 degC (for normal operation)
	Storage/Transport Temperature	-20 to 60 degC
	Ambient Humidity	20 to 80% RH (Non-condensing)
Mechanical	Weight	2.0 kg (Without VESA Bracket), 2.5 kg (With VESA Bracket)
	Dimensions (W x H x D)	500 mm x 225 mm x 44 mm
	Cable Length	2300 mm +/- 100 mm

Installation Guidelines

USB Interface Connection: Both USB A-type connectors must always be connected directly to the host PC.
VESA Mounting: When utilizing an optional VESA bracket, mount the assembly to a structure capable of holding at least 10 kg of weight using 8-M4 x L10 screws.
Environmental Limits: Install in an area maintaining ambient operating temperatures between 5 and 40 degC and relative humidity between 20 to 80% RH without condensation.

Compliance and Certifications

Safety Standards: CSA (compliant when CSA mark is indicated on the connected host PC)
EMC Standards: CE Marking (compliant when CE mark is indicated on the connected host PC; EN 61000-3-2 and EN 61000-3-3 out of scope)
Regional EMC Conformity: C-Tick Marking and KC Marking (compliant when indicated on the connected host PC)

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

How is power supplied to the operation keyboard?

Power is provided directly through the 5 V DC USB bus connections of the host PC.

Must both USB cables be connected for complete functionality?

Both USB type A connectors must always be connected directly to the PC simultaneously.

What is the weight requirement for VESA mounting structures?

The mounting location must hold at least 10 kg when using the VESA bracket.
