Beckhoff IP2040-B200 Lightbus Fieldbus Box Module

Hanya 10 item tinggal dalam stok

Pengilang: BECKHOFF
No. Produk: IP2040-B200
Negara asal:Jerman
Jenis Produk: Fieldbus Box Modules
Pembayaran: T/T, Western Union
Berat: 250g
Dimensi: 30 mm x 210 mm x 26.5 mm
Pelabuhan penghantaran: Xiamen
Jaminan: 12 bulan

Description

Designed for decentralized installation directly in harsh industrial environments, the Beckhoff IP2040-B200 digital output module establishes reliable connections between control networks and field-level actuators. This Lightbus Fieldbus Box features 8 digital outputs capable of switching loads up to 2 A per channel, with a cumulative module current of up to 12 A. By operating on the high-speed Lightbus fiber-optic ring system, the unit ensures high noise immunity and fast signal transmission over long distances.

The module is housed in a compact, rugged PA6 polyamide enclosure with an IP65/66/67 protection rating, allowing direct machine mounting without an electrical enclosure. This reduces wiring overhead, simplifies diagnostics, and optimizes space within decentralized automation systems. Connections to the actuators are established via secure 8 mm snap-type connectors, providing robust mechanical stability against shock and vibration.

Features

8-channel digital output configuration (24 V DC)
Lightbus fiber-optic system interface with 2.5 Mbaud transmission rate
2 A maximum load current per channel (individually short-circuit proof)
High cumulative current limit of up to 12 A
Direct machine mounting with IP65/66/67 rated environmental protection
Fibre-optic physical layer provides immunity to electromagnetic interference (EMI)
Comprehensive diagnostics and configuration capabilities via KS2000 or the master controller

Applications

Decentralized machine control and factory automation
Material handling and conveyor systems
Assembly lines and packaging machinery
Environments with severe electromagnetic interference (EMI)

Technical Specifications

Manufacturer	Beckhoff
Model / Part Number	IP2040-B200
Product Type	Fieldbus Box Module
Fieldbus Protocol	Lightbus
Number of Outputs	8
Output Connections	8 mm, snap-type
Nominal Output Voltage	24 V DC (-15 % / +20 %)
Max. Output Current	2 A per channel (individually short-circuit proof)
Total Module Current	Max. 12 A (channel 0 to 3: max 4 A, 4 to 5: max 4 A, 6 to 7: max 4 A)
Load Types Supported	Ohmic, inductive, lamp load
Data Transfer Rate	2.5 Mbaud
Bus Interface	2 x fiber-optic socket for plug ZS1020-0010
Data Transfer Medium	APF (plastic) fiber-optic conductor (1,000 micrometers)
Power Supply Connection	2 x M8 male socket, 4-pin (feed only, no downstream connection)
Electrical Isolation	Control voltage to fieldbus: Yes
Enclosure Material	PA6 (Polyamide)
Protection Rating	IP65, IP66, IP67 (conforms to EN 60529)
Operating Temperature	0 to +55 degC
Storage Temperature	-25 to +85 degC
Vibration / Shock Resistance	Conforms to EN 60068-2-6 / EN 60068-2-27
Dimensions (W x H x D)	30 mm x 210 mm x 26.5 mm
Weight	Approx. 250 g

Connections and Interfaces

Connection Point	Type / Specification	Function
Bus In / Bus Out	2 x Fiber-optic socket	Lightbus communication ring connection
Power Feed	2 x M8 male socket, 4-pin	24 V DC control and load voltage input
Outputs 0 to 7	8 mm snap-type sockets	Actuator signal connection

Installation Guidelines

Mount the module directly onto flat surfaces using 2 fixing holes suitable for M3 screws.
Ensure that the minimum bending radius of the APF plastic fiber-optic cables is maintained during routing to prevent signal attenuation.
Always cover unused M8 and 8 mm sockets with IP67 protective caps to preserve the environmental seal.
Avoid installing the module in areas subject to continuous fluid pooling or direct high-pressure spray.

Compliance and Certifications

CE
UL
EMC Immunity/Emission: EN 61000-6-2 / EN 61000-6-4

Key Features:

#Beckhoff Lightbus #Fieldbus Box Modules

What communication protocol does the Beckhoff IP2040-B200 use?

The IP2040-B200 uses the Lightbus fiber-optic ring network with a transmission speed of 2.5 Mbaud.

What is the maximum output current limit per channel on the IP2040-B200?

Each of the 8 digital outputs can switch a maximum load of 2 A per channel, with a total module cumulative limit of 12 A.

Does this module require a separate control cabinet?

No, with its IP65/66/67 rating and rugged PA6 housing, the IP2040-B200 is designed for decentralized machine-level installation without an enclosure.

What type of connection is used for the actuator signals?

Actuators are connected via standard 8 mm snap-type sockets for quick and vibration-resistant installation.
