Bently Nevada 330102-00-28-10-02-00 3300 XL 8 mm Proximity Probe with Armor

Bently Nevada 330102-00-28-10-02-00 3300 XL 8 mm Proximity Probe with Armor

Hanya 4 item tinggal dalam stok

  • Pengilang: Bently Nevada

  • No. Produk: 330102-00-28-10-02-00

  • Negara asal:Amerika Syarikat

  • Jenis Produk: 3300 XL 8 mm Proximity Probe

  • Kod bar: 8537101190

  • Pembayaran: T/T, Western Union

  • Berat: 320g

  • Dimensi: 152 mm x 152 mm x 25 mm (H x W x D)

  • Pelabuhan penghantaran: Xiamen

  • Jaminan: 12 bulan

Lihat butiran penuh
Penerangan Produk
FAQ
Penghantaran Pemulangan
Butiran tambahan
Ulasan

Description

330102-00-28-10-02-00 is a 3300 XL 8 mm proximity probe with 3/8-24 UNF threads and flexible stainless steel armor, configured with 0.0 in unthreaded length, 2.8 in case length, 1.0 m total length, ClickLoc connector, and standard cable.

This armored configuration features a 2.8 in overall case length (Option 28) and is fully threaded (Option 00 unthreaded length). It employs a 1.0 m cable (Option 10) fitted with a miniature coaxial ClickLoc connector (Option 02) without a connector protector. Unlike variants configured with the -05 agency approval option, this model uses the -00 option, which is suitable for standard, non-hazardous areas where special industrial certifications are not required.

Features

  • Flexible stainless steel armor (AISI 302 or 304) with FEP outer jacket provides protection in harsh mechanical environments.
  • Fully threaded 3/8-24 UNF-2A case with 2.8 in total case length and 0.0 in unthreaded length.
  • Standard triaxial cable with 1.0 m total length for proximity transducer chains.
  • Miniature coaxial ClickLoc connector without protector provides standard connection to extension cables.
  • General application design (Option 00) for installation where hazardous area approvals are not required.

Applications

  • Shaft vibration and axial position measurement on industrial rotating machinery.
  • Asset protection monitoring in steam/gas turbines, centrifugal compressors, and generators.
  • Bearing clearance and oil-film thickness monitoring in non-hazardous industrial environments.

Ordering Information

Option Code on This SKU Description
Orderable Part Number 330102-00-28-10-02-00 3300 XL 8 mm proximity probe with armor, 3/8-24 UNF thread
A - Unthreaded Length Option 00 0.0 in (fully threaded)
B - Overall Case Length Option 28 2.8 in case length (71.1 mm)
C - Total Length Option 10 1.0 meter (3.3 feet)
D - Connector and Cable-Type Option 02 Miniature coaxial ClickLoc connector, standard cable
E - Agency Approval Option 00 Agency approvals not required

Technical Specifications

Manufacturer Bently Nevada
Part Number 330102-00-28-10-02-00
Series 3300 XL 8 mm Proximity Transducer System
Tip Diameter 8.0 mm (0.31 in)
Case Thread 3/8-24 UNF-2A
Armor Material Flexible AISI 302 or 304 SST with FEP outer jacket
Case Material AISI 303 or 304 stainless steel
Tip Material Polyphenylene sulfide (PPS)
Cable Length 1.0 m (3.3 feet)
Unthreaded Length 0.0 in
Case Length 2.8 in (71.1 mm)
Connector Type Miniature coaxial ClickLoc male
Cable Type 75 Ohm triaxial standard cable
DC Resistance (Center to Outer) 7.59 +/- 0.50 Ohms
Tensile Strength 330 N (75 lbf) maximum rated probe case to probe lead
Minimum Bend Radius 25.4 mm (1.0 in)
Operating Temperature -52 degC to +177 degC
Weight 0.32 kg
Dimensions 152 mm x 152 mm x 25 mm (H x W x D) (coiled)

Connections and Interfaces

Connector Component Type Material
Probe Connector Miniature coaxial ClickLoc (Male) Gold-plated brass or gold-plated beryllium copper

Installation Guidelines

  • Do not exceed the maximum rated installation torque of 11.2 Nm (100 in-lbf) for standard forward mounted probes.
  • Observe the minimum permissible cable bend radius of 25.4 mm (1.0 in) during routing to prevent jacket or shield failure.
  • Ensure the probe tip is clear of any surrounding metal side-clamping structures to avoid calibration errors.
  • Tighten ClickLoc connectors finger tight to achieve a proper mechanical and electrical connection.
Loading product navigation…

RECOMMENDED RELATED MODELS

Product Image Model Number / Title Condition Availability Action
330901-00-78-10-02-00 Bently Nevada 330901-00-78-10-02-00 Probe Proximity NSv 3300 XL Original New In Stock View Details
330104-00-04-10-11-01 Bently Nevada 330104-00-04-10-11-01 Probe Proximity 8 mm 3300 XL Original New In Stock View Details
330104-00-04-10-02-01 Bently Nevada 330104-00-04-10-02-01 Probe Proximity 8 mm 3300 XL Original New In Stock View Details
Key Features:
#Bently Nevada 3300 XL #Proximity Probes

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

Technical Datasheet

Bently Nevada 330102-00-28-10-02-00 3300 XL 8 mm Proximity Probe with Armor

Download Open in new tab

What configuration is specified by the 330102-00-28-10-02-00 orderable code?
This code specifies a 3300 XL 8 mm proximity probe with flexible stainless steel armor, featuring a fully threaded 3/8-24 UNF case of 2.8 inches (Option 28), 0.0 inches of unthreaded length (Option 00), 1.0 meter total cable length (Option 10), standard ClickLoc coaxial connector (Option 02), and no agency approvals (Option 00).

Does this probe model require or include a connector protector?
No, this specific configuration (Option 02) includes a standard miniature coaxial ClickLoc connector without a connector protector. Sibling configuration Option 01 is required if a connector protector is needed.

What is the function of the flexible armor on this proximity probe?
The AISI 302 or 304 stainless steel armor with FEP outer jacket provides physical protection to the FEP-insulated coaxial cable, making it suitable for environments where cable abrasion or mechanical impact may occur.

Can this probe be used in hazardous areas?
No, this configuration features Option 00 for agency approvals, meaning it is not certified for hazardous areas. If explosive atmosphere certifications are required, the -05 option should be ordered instead.
