Bently Nevada 330730-040-00-00 3300 XL 11 mm Extension Cable

Bently Nevada 330730-040-00-00 3300 XL 11 mm Extension Cable

Hanya 3 item tinggal dalam stok

  • Pengilang: Bently Nevada

  • No. Produk: 330730-040-00-00

  • Negara asal:Amerika Syarikat

  • Jenis Produk: 3300 XL 11 mm Extension Cable

  • Kod bar: 8537101190

  • Pembayaran: T/T, Western Union

  • Berat: 180g

  • Dimensi: 50 mm x 100 mm x 100 mm (H x W x D)

  • Pelabuhan penghantaran: Xiamen

  • Jaminan: 12 bulan

Lihat butiran penuh
Penerangan Produk
FAQ
Penghantaran Pemulangan
Butiran tambahan
Ulasan

Description

Option 040 (4.0 m cable length) and Option 00 (standard unarmored cable with no agency approvals required) specify this 3300 XL 11 mm extension cable configuration — 330730-040-00-00.

This coaxial extension cable operates as a link in 3300 XL 11 mm proximity transducer systems, connecting the 11 mm probe to a compatible Proximitor sensor. Unlike armored (Option 01) or FluidLoc (Option 10) alternatives, this standard FEP-insulated coaxial line is used in industrial environments where mechanical hazards, abrasive wear, or extreme fluid exposure are absent. The 4.0-meter cable length combines with a 1.0-meter probe to achieve the required 5.0-meter total system length.

Features

  • Cable Length: 4.0 meters (13.1 feet) length.
  • Cable Construction: Standard FEP jacketed 75 ohm triaxial cable.
  • Protection Rating: Standard unarmored configuration.
  • Connector Setup: Standard ClickLoc coaxial connectors without protective sleeves.
  • Agency Approval: Option 00 specifies that no safety agency approvals are required.

Applications

This extension cable is used in machinery protection loops across multiple rotating equipment applications, including:

  • Steam and gas turbine shaft vibration and axial position measurement.
  • Centrifugal and axial compressor vibration monitoring.
  • Critical rotating machinery protection utilizing 11 mm proximity probe installations.

Ordering Information

Option / Segment Code on This SKU Description
Orderable Part Number 330730-040-00-00 3300 XL 11 mm Extension Cable
A - Cable Length Option 040 4.0 meters (13.1 feet)
B - Connector and Cable Option 00 Standard cable
C - Agency Approval Option 00 Not required

Technical Specifications

Parameter Value / Specification
Manufacturer Bently Nevada
Model / SKU 330730-040-00-00
Cable Construction 75 ohm triaxial, fluoroethylene propylene (FEP) insulated
Cable Weight 45 g/m (0.5 oz/ft)
Cable Length 4.0 meters (13.1 feet)
Connector Type Miniature coaxial ClickLoc connectors (female to male)
Connector Material Gold-plated brass
DC Resistance (Rjacket) 1.0 +/- 0.25 ohms (coaxial conductor to coaxial conductor)
DC Resistance (Rcore) 0.3 +/- 0.1 ohms (center conductor to center conductor)
Extension Cable Capacitance 69.9 pF/m (21.3 pF/ft) typical
Maximum Rated Tensile Strength 270 N (60 lb) at probe lead to extension cable connectors
Minimum Bend Radius 25.4 mm (1.0 in)
Operating and Storage Temperature -52 degC to +177 degC (-62 degF to +351 degF)
Relative Humidity Limits 100% condensing, non-submersible when connectors are protected

Installation Guidelines

  • Verify that the extension cable length (4.0 meters) and the probe length (typically 1.0 meter) sum to the total system length expected by the Proximitor sensor (5.0 meters).
  • Avoid routing cables near high-voltage lines or sources of electromagnetic interference to prevent signal corruption.
  • Always observe the minimum bend radius of 25.4 mm (1.0 in) during installation and routing.
  • Join the ClickLoc connectors finger-tight; do not exceed the maximum torque limit of 0.565 N-m (5 in-lb).

Compliance and Certifications

  • EMC: Directive 2014/30/EU (EN 61000-6-2, EN 61000-6-4)
  • RoHS: Directive 2011/65/EU
  • China RoHS compliant (EFUP designation)
Loading product navigation…

RECOMMENDED RELATED MODELS

Product Image Model Number / Title Condition Availability Action
330901-00-78-10-02-00 Bently Nevada 330901-00-78-10-02-00 Probe Proximity NSv 3300 XL Original New In Stock View Details
330104-00-04-10-11-01 Bently Nevada 330104-00-04-10-11-01 Probe Proximity 8 mm 3300 XL Original New In Stock View Details
330104-00-04-10-02-01 Bently Nevada 330104-00-04-10-02-01 Probe Proximity 8 mm 3300 XL Original New In Stock View Details
Key Features:
#Bently Nevada 3300 XL #Extension Cables

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

Technical Datasheet

Bently Nevada 330730-040-00-00 3300 XL 11 mm Extension Cable

Download Open in new tab

What is the configuration of the Bently Nevada 330730-040-00-00 extension cable?
This SKU represents a standard 4.0-meter (13.1-foot) extension cable with no mechanical armor (Option 00) and no agency approvals (Option 00). It is constructed with standard FEP insulation and uses ClickLoc coaxial connectors.

What system total length is this cable intended for?
This 4.0-meter extension cable is designed to pair with a 1.0-meter 11 mm proximity probe to create a complete 5.0-meter proximity transducer system length.

What is the minimum bend radius for this FEP-insulated coaxial cable?
The minimum bend radius is 25.4 mm (1.0 inch), whether installing standard or armored variants of the 330730 series.

What is the maximum rated torque for the coaxial connector?
Connectors should be joined finger-tight. The maximum rated connection torque is 0.565 N-m (5 in-lb).
