Inverter Kompak Pelbagai Fungsi Siri MX2 Omron 3G3MX2-A2007-V1

Description

Real-time machine control and precise motor speed regulation are driven by the 3G3MX2-A2007-V1 adjustable frequency AC drive, a key component of the Omron MX2 Series of compact industrial inverters. This multi-function compact inverter is engineered to deliver high starting torque and dynamic speed control for three-phase induction motors in demanding automation environments. Featuring advanced current vector control, the drive achieves up to 200% starting torque at near-zero speed (0.5 Hz), making it highly suitable for heavy-duty load regulation and high-inertia start-stop profiles.

The unit features integrated safety functionality complying with machinery safety directives, eliminating the need for redundant external contactors in emergency stop circuits. Standard industrial communication interfaces and modular expansion options ensure seamless integration into distributed control architectures, while the physical form factor enables high-density side-by-side DIN rail mounting inside industrial enclosures.

Features

• High starting torque of 200% at 0.5 Hz for heavy-load starting applications.
• Advanced current vector control and V/f control capability.
• Integrated safety torque off (STO) function complying with ISO 13849-1 Cat 3 PLd.
• Modbus RTU communication interface built-in via RS-485.
• Dual rating options to optimize drive selection for Constant Torque (CT) or Variable Torque (VT) profiles.
• Side-by-side mounting capability without de-rating to optimize enclosure space.

Applications

• Material handling and conveyor systems.
• Packaging and labeling machinery.
• Pumps, fans, and commercial HVAC blowers.
• Machine tool axes and auxiliary spindle controls.
• Food processing and mixing equipment.

Technical Specifications

Installation Guidelines

• Mounting Position: Install the inverter vertically on a flat, non-flammable vertical surface (such as a metal panel) to ensure proper heat dissipation.
• Clearances: Maintain a minimum clearance of 100 mm above and below the unit, and 50 mm on either side for adequate airflow.
• Wiring and Grounding: Strictly connect the ground terminal (PE) to an independent ground. Use shielded cables for motor connections to reduce electromagnetic interference (EMI).
• Safety Precautions: Ensure input power lines (L1, L2, L3) are connected only to the input terminals and never to the output motor terminals (U, V, W) to prevent catastrophic device failure.

Compliance and Certifications

• CE Marked (Low Voltage and EMC Directives)
• UL and cUL Listed
• RoHS Compliant
• Functional Safety: ISO 13849-1 Cat 3 PLd
