Pemacu Kekerapan Boleh Laras Altivar 212 Schneider ATV212WU40N4C

Description

The ATV212WU40N4C is a Variable Speed Drive from the Altivar 212 series, manufactured by Schneider Electric to provide optimized motor control in industrial and commercial HVAC and pumping applications. This drive is rated for a power output of 4 kW and operates on a 480 V three-phase supply. It is equipped with a class C1 EMC filter to ensure high-level electromagnetic compatibility within sensitive electrical networks.

Encased in an IP55-rated housing, the ATV212WU40N4C offers enhanced protection against dust and water jets, making it suitable for environments where exposure to contaminants is a factor. This drive facilitates precise speed regulation, contributing to improved operational efficiency and energy management for various motor-driven systems.

Features

• Optimized for HVAC, pump, and fan control
• Integrated Class C1 EMC filter for superior noise suppression
• Rated for 4 kW output at 480 V (3-phase)
• IP55 protection degree for operation in demanding environments
• Reliable motor control for energy-efficient system management

Applications

• Heating, ventilation, and air conditioning (HVAC) systems
• Centrifugal pump stations
• Industrial fan and blower systems
• Building management and circulation equipment

Technical Specifications

Installation Guidelines

• Mounting: Mount the drive in a vertical position on a flat, non-flammable surface, ensuring proper orientation to maintain the IP55 sealing integrity.
• Environment: Ensure the ambient temperature is within the specified operating range and protect the unit from direct sunlight and excessive humidity.
• Ventilation: Maintain required clearance distances around the unit to facilitate effective cooling and heat dissipation.
• Grounding: Connect the drive to a secure, low-impedance earth ground to ensure safe operation and EMC performance.
• Wiring: Use screened cables for motor connections to maintain the effectiveness of the Class C1 EMC filter.
