Schneider Electric ATV71HD18N4S337 Pemacu Frekuensi Boleh Ubah Altivar 71

Description

The ATV71HD18N4S337 is a high-performance Altivar 71 variable speed drive from Schneider Electric, engineered to provide precise motor control for industrial applications. This drive is rated for an output power of 18.5 kW (25 HP) and is designed for operation with a 480V three-phase power supply. It comes factory-equipped with an integrated EMC filter to reduce electromagnetic interference in sensitive electrical environments and includes a graphic terminal for intuitive navigation, parameter configuration, and monitoring of system diagnostics. The Altivar 71 series is widely recognized for its advanced control algorithms and adaptability, making it suitable for demanding torque and speed regulation tasks.

Features

• Power Rating: 18.5 kW (25 HP) for robust motor control.
• Input Voltage: Optimized for 480V three-phase networks.
• Integrated EMC Filter: Reduces conducted and radiated emissions for compliance with industrial standards.
• Graphic Terminal: High-resolution display for easy access to menus, error logs, and motor performance data.
• Versatility: Suitable for a wide range of industrial applications including pumps, fans, and complex machinery.

Applications

• Variable torque applications such as HVAC systems, centrifugal pumps, and fans.
• Constant torque applications such as conveyors, mixers, and crushers.
• High-precision motion control where speed stability is critical.
• Industrial manufacturing processes requiring integration with PLC architectures.

Technical Specifications

Installation Guidelines

• Mounting: Install the drive in a clean, ventilated enclosure to prevent dust buildup and overheating.
• Grounding: Ensure a solid, low-impedance connection to the protective earth (PE) terminal to maximize the effectiveness of the integrated EMC filter.
• Shielding: Use shielded motor cables and route them separately from control and signal wiring to mitigate EMI.
• Environment: Ensure the ambient temperature remains within the manufacturer’s specified limits, as the Altivar 71 relies on internal cooling fans for thermal management.
• Configuration: Use the graphic terminal to perform the initial setup and "Auto-tuning" to optimize the drive performance for your specific motor.
