Schneider Electric LXD1E7 TeSys D Gegelung Kontaktor

Description

The LXD1E7 is a replacement 48V AC control coil designed for the TeSys D series contactors, specifically compatible with LC1D09-38 and T20-T40 models. This component serves as the electromagnetic actuator for the contactor, ensuring precise and reliable switching operations within industrial electrical distribution systems. Manufactured for high durability, the LXD1E7 provides consistent performance in demanding control circuit applications.

Features

• Compatibility: Designed for TeSys LC1D09 through LC1D38 contactors
• Control Voltage: 48V AC
• Series: TeSys D
• Reliable Actuation: Optimized for standard industrial switching cycles

Technical Specifications

Installation Guidelines

• Safety: Ensure the control circuit is de-energized and locked out before attempting to replace the coil.
• Compatibility: Verify that the contactor base unit is within the compatible LC1D09-38 range before installation.
• Replacement: Access the contactor housing according to the manufacturer's maintenance manual, remove the existing coil, and slide the LXD1E7 into position, ensuring proper seating of the magnetic core.
• Wiring: Connect the control voltage leads to the coil terminals, ensuring tight, secure connections to prevent contact resistance.
