Modul Output Digital Schneider Modicon Premium TSXDSY08R5AC

Description

The TSXDSY08R5AC is a Discrete Output Module within the Modicon Premium range, engineered by Schneider Electric to provide reliable switching control for industrial automation tasks. This module features 8 relay-protected outputs capable of handling a voltage range from 24V to 240V AC, with a load capacity of 5A per channel. Designed for high-reliability applications, the TSXDSY08R5AC integrates seamlessly into Modicon Premium PLC backplanes, offering robust performance for controlling actuators, solenoids, and other electrical loads. Its architecture ensures efficient signal distribution and system-wide reliability, making it a critical component for maintaining or retrofitting established control systems.

Features

• 8 relay-protected discrete outputs
• Voltage range: 24 to 240V AC
• Load capacity: 5A per output channel
• Designed for Modicon Premium PLC integration
• Reliable switching for diverse industrial electrical loads

Applications

• Control cabinet automation and relay logic
• Industrial machinery control sequencing
• Actuator and solenoid interface management
• Automated manufacturing line switching
• Process control equipment interfacing

Technical Specifications

Installation Guidelines

• Ensure the PLC rack power supply is disconnected before mounting or removing the TSXDSY08R5AC module to prevent electrical damage.
• Secure the module firmly into the Modicon Premium rack backplane using the provided locking mechanism.
• Verify that the wiring connected to the relay outputs does not exceed the maximum voltage (240V AC) or current (5A) specifications to prevent relay failure.
• Use appropriate wire gauges for the load current and ensure all terminal screws are tightened to the specified torque.
• Group wiring by load type and maintain separation from sensitive signal or communication cables to minimize induced noise.
• Conduct a full I/O mapping verification in the PLC software project before engaging the outputs with actual field devices.
