Allen-Bradley 1492-AIFM16-F-3 Analog Interface Module

SKU 1492-AIFM16-F-3

In stock

12-month warranty
Free returns within 30 days

Manufacturer: Allen-Bradley
Product No.: 1492-AIFM16-F-3
Country of origin:United States
Product Type: Analog Interface Modules
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 350g
Dimensions: 83 mm x 125 mm x 71 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months

Description

The Allen-Bradley 1492-AIFM16-F-3 is a fusible 16-channel analog input interface module designed for programmable controller wiring systems. It features integrated 24V DC blown fuse indicators and provides 3 terminals per channel for field-side signal termination. The module incorporates fuse holders for channel protection and DIP switches that allow unused inputs to be jumpered to module common on compatible analog modules.

Features

Fusible 16-channel input architecture with 3 terminals per channel.
Integrated 24V DC blown fuse indicators for rapid diagnostic field status.
Configurable DIP switches to jumper unused inputs to module common in the closed (ON) position.
Eighteen field-side shield terminals jumpered together internally and tied to the D-shell housing.
On-board fuse holders accommodating $5\times20\text{ mm}$ fuses.

Applications

Analog signal termination and channel protection for programmable controller I/O systems.
Field sensor wiring integration requiring individual channel fusing and blown fuse indication.

Technical Specifications

Parameter	Specification
Manufacturer	Allen-Bradley / Rockwell Automation
Model	1492-AIFM16-F-3
Module Type	Analog Interface Module (AIFM)
Number of Inputs	16 Channels (Fusible)
Terminals per Channel	3 Terminals
Indicators	24V DC Blown Fuse Indicators
Fuse Size Capacity	5 × 20 mm
Maximum Current Rating	2 A per input, 12 A per AIFM
DIP Switch Settings	Default position: OPEN/OFF/NOT jumpered together
Shield Connection	18 field-side terminals jumpered to D-shell housing

Installation Guidelines

Compatibility: Ensure field signal voltage and current ratings do not exceed the module specifications.
Fusing: Install 5 × 20 mmfuses into the integrated fuse holders before commissioning; do not exceed 2 A per input channel or 12 A total for the entire module.
Power Source Isolation: Note that fuse clips and blown fuse indicators connect internally to a single power source field-side terminal; all connected inputs must reference the same power source.
Unused Inputs Configuration: For analog modules supporting unused input jumpering, set the corresponding DIP switches to the ON position to connect unused inputs to module common.
Shielding: Connect cable shields to the designated field terminals to utilize the internal ground loop to the D-shell housing.

FAQ

What size fuses are used with the module?

The module uses standard 5x20 mm fuses.

What are the maximum current limits for the device?

The maximum current limits are 2 A per input channel and 12 A total per AIFM module.

What function do the on-board DIP switches serve?

When closed (ON position), the DIP switches jumper unused inputs to module common for compatible analog modules.
