B&R X20DS1319 X20 System Digital Input Module

SKU X20DS1319

In stock
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: B&R

  • Product No.: X20DS1319

  • Country of origin:United States

  • Product Type: I/O module

  • Payment: T/T, Western Union

  • Weight: 1000g

  • Shipping port: Xiamen

  • Warranty: 12 months

Overview of the Hardware

The X20DS1319 (X20 DS 1319) is a high-density digital input module engineered for the B&R X20 System platform. Designed to deliver deterministic signal acquisition in demanding industrial environments such as chemical processing, power generation, and high-speed packaging, this module ensures seamless integration with standard X20 backplane configurations. By providing real-time I/O status feedback and reliable electronic protection, the X20DS1319 minimizes system downtime, optimizes control loop efficiency, and guarantees high operational availability in critical automation architectures.

System Architecture and Technical Features

The module features advanced internal diagnostics and localized status monitoring via integrated LEDs. Each channel is equipped with individual functional indicators, alongside global status lights for operating state and module errors, enabling rapid field troubleshooting without external software tools. Power management is highly optimized, segregating low-power bus communication from internal I/O electronics to prevent cross-talk and maintain signal integrity. Built-in software-readable diagnostics allow predictive maintenance strategies, alerting the central controller of any performance anomalies before localized faults escalate into systemic shutdowns.

Specifications Table

Attribute Technical Data
Model X20DS1319
Brand B&R (Automation)
Origin Austria
Module Type Digital Input Module
B&R ID Code 0x2547
Status Indicators Channel I/O status, operating state, module status
Diagnostics Module run/error (LED and software), outputs status
Bus Power Consumption 0.01 W
Internal I/O Power Consumption 1.5 W
Operating Temperature 0 to 55 deg C
Dimensions 12.5 x 99 x 74 mm
Weight 0.09 kg (Module only) / 1.0 kg (Shipping weight)

Frequently Asked Questions

How does the X20DS1319 handle localized diagnostic reporting?

The module utilizes a dual-layer diagnostic framework. Field technicians can instantly verify channel status and module readiness via the front-facing LEDs. Concurrently, the module transmits real-time status registers over the X20 backplane, allowing the central PLC or DCS to log errors, monitor signal quality, and trigger automated system alerts.

Is this module hot-swappable within the X20 backplane architecture?

Yes, the X20 System architecture supports hot-swapping. The X20DS1319 can be inserted or removed from the terminal block slide-in base during active system operation without disrupting the communication of adjacent modules, significantly reducing MTTR (Mean Time To Repair).

What are the primary factors behind the difference between the net weight and the shipping weight?

The net weight of the electronic module itself is under 0.1 kg. The 1.0 kg shipping weight reflects industrial-grade protective bulk packaging, anti-static shielding bags, structural documentation inserts, and ruggedized outer boxing required to prevent mechanical or ESD damage during international transit.


Engineering Installation and Safety Field Guide

  • Bus Module Alignment and Terminal Insertion: Prior to applying control voltage, ensure the slide-in X20DS1319 module is fully seated into its corresponding X20BM11 bus module. Visual verification of the mechanical locking tabs is mandatory to prevent intermittent backplane connections or communication bus timeouts.

  • Thermal Management and Clearance: The module is designed for vertical DIN-rail mounting. Maintain a minimum clearance of 30 mm above and below the module rack to promote natural convection cooling. Ensure ambient enclosure temperatures do not exceed 55 deg C under full load conditions.

  • Shielding and Grounding Standards: To mitigate electromagnetic interference (EMI) from high-power field devices, all sensor cables must be properly shielded. Terminate the cable shields directly at the grounding busbar located at the entry point of the control enclosure using low-impedance grounding clamps.
