BECKHOFF C3350-0070 C33xx Series 19-inch Panel PC

SKU C3350-0070

In stock

12-month warranty
Free returns within 30 days

Manufacturer: BECKHOFF
Product No.: C3350-0070
Country of origin:Germany
Product Type: Panel PCs
Payment: T/T, Western Union
Weight: 21000g
Dimensions: 48.27 cm x 44.4 cm x 28.2 cm
Shipping port: Xiamen
Warranty: 12 months

Description

Engineered for demanding industrial control environments, the BECKHOFF C3350-0070 integrates a high-performance ATX motherboard into a robust 19-inch built-in housing. This industrial panel PC features a built-in 15-inch display with a resolution of 1024 x 768 pixels, combined with an alphanumeric US-layout keyboard and 10 dedicated PLC keys with LED indicators. Built for durability, the unit features a stainless steel based housing with an aluminum front and a lockable front flap to protect user interfaces in harsh plant environments.

Driven by an Intel Celeron G3900 2.8 GHz dual-core processor, the BECKHOFF C3350-0070 provides stable and deterministic control for TwinCAT 2 and TwinCAT 3 runtime systems. Its versatile motherboard architecture supports up to 6th and 7th generation Intel processors, ensuring long-term compatibility and scalability. System reliability is further enhanced by an on-board SATA RAID 1 controller and generous physical expansion options via PCIe and PCI slots, allowing seamless integration of specialized industrial communication cards and fieldbus interfaces.

Features

Rugged stainless steel housing equipped with an aluminum front panel and a lockable front flap.
Integrated 15-inch display with a native 1024 x 768 resolution.
Alphanumeric PC keyboard (US layout) and 10 integrated PLC function keys with LED status indicators.
Flexible expansion capabilities supporting both PCIe (PCI Express) and legacy PCI cards.
Dual on-board 100/1000BASE-T Ethernet interfaces for independent network segmenting.
SATA RAID 1 controller on-board to ensure high data availability and redundant storage profiles.

Applications

Automotive assembly line visualization and machine control.
Heavy industrial process monitoring and SCADA systems.
Power generation and distribution control panels.
Custom test bench automation and lab instrumentation systems.

Technical Specifications

CategoryTechnical ParameterValue / Specification

Manufacturer	Beckhoff Automation	C3350-0070
Device Type	19-inch Built-in Industrial PC	C3350
Housing Material	Stainless steel based housing with aluminum front and lockable front flap	IP65 (front side), IP20 (rear side)
Operating Temperature	0 to 55 degC	15-inch / 1024 x 768 pixels
Keyboard Layout	Alphanumeric PC keyboard in US layout; 10 PLC keys with LED and slide-in labels	Intel Celeron G3900 2.8 GHz, 2 cores (TC2, TC3: 50)
Motherboard	ATX motherboard for 6th/7th generation Intel Celeron, Pentium, Core i3/i5/i7	4 GB DDR4 RAM
Expansion Slots	2 x PCIe-x1, 1 x PCIe-x4, and 1 x PCIe-x16 (for up to 240 mm cards); 2 x PCI and 1 x PCIe-x4 (for full-length cards)	2 x 100/1000BASE-T on-board
Storage Controllers & Drive	On-board SATA RAID 1 controller; 3.5-inch 1 TB Hard Disk	4 x USB 3.0, 2 x DVI, 1 x DisplayPort, 1 x RS232, PS/2 keyboard and mouse
Power Supply	100 to 240 V AC	48.27 cm x 44.4 cm x 28.2 cm
Weight	19 kg (Shipping weight: 21 kg)	Compatible with standard industrial operating systems and TwinCAT runtime environment

Connections and Interfaces

Interface Type	Quantity	Function / Connection Type
USB 3.0	4	External peripheral connections
DVI	2	External secondary display outputs
DisplayPort	1	High-resolution digital display output
RS232	1	Serial interface (DB9) for legacy hardware and sensors
Ethernet	2	RJ45 100/1000BASE-T on-board interfaces
PS/2	2	Dedicated keyboard and mouse input ports

Installation Guidelines

Mounting: Ensure the device is installed in a cut-out profile matching the 19-inch standard parameters. Secure all rear mounting clamps to maintain the IP65 ingress protection rating on the front panel.
Grounding: Connect the functional earth terminal on the rear of the housing to the central grounding point of the control cabinet using a low-impedance conductor.
Ventilation: Provide a minimum clearance of 50 mm above and below the device inside the enclosure to facilitate natural convection and prevent heat build-up.
Cabling: Maintain separation between high-voltage power cables and signal/communication cables to prevent electromagnetic interference (EMI).

FAQ

What is the ingress protection rating for the BECKHOFF C3350-0070?

The front side of the Panel PC is rated IP65, offering protection against dust and water jets. The rear side is rated IP20 and should be enclosed within a protective cabinet.

What processor is installed in this specific configuration?

This unit is configured with an Intel Celeron G3900 dual-core processor running at 2.8 GHz, optimized for TwinCAT runtime applications.

Can I expand the system with additional interface cards?

Yes. The C3350-0070 offers multiple expansion slots, including 2 x PCIe-x1, 1 x PCIe-x4, and 1 x PCIe-x16 for cards up to 240 mm long, plus 2 x PCI and 1 x PCIe-x4 slots for full-length cards.

Does this Panel PC support RAID configurations?

Yes, it features an on-board SATA RAID 1 controller to allow for redundant data storage configurations.

What are the input power requirements for the C3350-0070?

The integrated industrial power supply accepts a wide input voltage range of 100 to 240 V AC.
