BECKHOFF C5210-0030 Industrial PC

SKU C5210-0030

In stock

12-month warranty
Free returns within 30 days

Manufacturer: BECKHOFF
Product No.: C5210-0030
Origin Germany
Product Type: Industrial PCs
Payment: T/T, Western Union
Weight: 19.0 kg
Dimensions: 482.7 x 44 x 493.8 mm
Shipping port: Xiamen
Warranty: 12 months

Product Description

Description

The BECKHOFF C5210-0030 is a 19-inch slide-in Industrial PC designed for installation in control cabinets and server racks. Built upon a stainless steel housing with a height of 1 rack unit (1U) and a lockable front flap, this industrial computing unit provides a reliable platform for centralized automation, visualization, and data acquisition tasks within industrial environments.

Equipped with a 3.5-inch motherboard supporting Intel processors and featuring integrated peripheral interfaces, the C5210-0030 integrates into industrial control architectures. It includes onboard Ethernet ports, USB connections, and modular expansion capabilities via internal PCIe slots, supporting deployment alongside TwinCAT automation software.

Features

19-inch slide-in Industrial PC housed in a 1 rack unit (1U) stainless steel chassis
Lockable front flap providing physical security and access to integrated front-side interfaces
3.5-inch motherboard architecture configured for high-performance industrial applications
Dual onboard 100/1000BASE-T Ethernet interfaces for network communication
Onboard SATA RAID 1 controller supporting data redundancy configurations
Modular expansion via PCIe module slots for custom interface integration

Applications

Centralized machine control and automation computing in industrial plants
Industrial plant visualization and human-machine interface (HMI) data processing
Data logging, quality tracking, and supervisory control system execution
Rack-mounted cabinet installations for manufacturing and process automation

Technical Specifications

General

Parameter	Specification
Manufacturer	BECKHOFF
Exact Model	C5210-0030
Device Type	19-inch slide-in Industrial PC
Housing	Stainless steel based housing, 1 rack unit, with lockable front flap

Processing and Memory

Parameter	Specification
Motherboard	3.5-inch motherboard for 6th/7th generation Intel Celeron, Pentium, Core i3/i5/i7
Processor	Intel Celeron G3900TE 2.3 GHz, 2 cores
Main Memory	4 GB DDR4 RAM
Graphic Adapter	Integrated in the processor

Storage and Drives

Parameter	Specification
Hard Disks / Flash	3.5-inch hard disk, 1 TB
RAID Controller	On-board SATA RAID 1 controller
Removable Frames	2 removable frames for hard disks

Interfaces and Communication

Parameter	Specification
Ethernet	2 x 100/1000BASE-T on-board
USB Ports (Rear)	4 x USB 3.0
USB Ports (Front)	2 x USB 2.0 behind the lockable front flap
Serial Interfaces	1 x RS232 at the rear
Video Interfaces	1 x DVI
Controls	Reset key and ATX key behind front flap

Electrical and Power

Parameter	Specification
Power Supply	100 to 240 V AC

Mechanical and Environmental

Parameter	Specification
Protection Rating	IP20
Operating Temperature	0 to 55 degC
Dimensions (W x H x D)	482.7 x 44 x 493.8 mm (19 inches x 1.7 inches x 19.44 inches)
Depth Behind Front	475 mm (18.7 inches)

Installation Guidelines

Verify that the exact model C5210-0030 matches your system requirements and cabinet space specifications before mounting.
Ensure all power sources to the control cabinet are de-energized and locked out prior to handling hardware.
Mount the 19-inch slide-in Industrial PC securely into the standard 19-inch rack using appropriate mounting hardware, ensuring adequate clearance for ventilation and cable routing.
Connect the appropriate power supply cables (100 to 240 V AC) to the unit, verifying proper grounding and voltage levels before applying power.
Connect necessary peripherals, network cables to the onboard Ethernet ports, and display devices to the DVI interface.
Power on the system and configure the operating environment and software parameters according to your application requirements.

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

What are the dimensions and form factor of the BECKHOFF C5210-0030?

The BECKHOFF C5210-0030 is a 19-inch slide-in Industrial PC with a 1 rack unit (1U) height, measuring 482.7 mm in width, 44 mm in height, and 493.8 mm in total depth (with a depth behind the front of 475 mm).

What processor and memory configuration comes standard with the BECKHOFF C5210-0030?

The BECKHOFF C5210-0030 comes equipped with an Intel Celeron G3900TE 2.3 GHz dual-core processor and 4 GB of DDR4 RAM mounted on a 3.5-inch motherboard.

What storage and RAID features are included in the BECKHOFF C5210-0030?

The BECKHOFF C5210-0030 includes a 1 TB 3.5-inch hard disk, an onboard SATA RAID 1 controller for data mirroring, and two removable frames for hard disks.

What network and peripheral interfaces are available on the BECKHOFF C5210-0030?

The BECKHOFF C5210-0030 features two 100/1000BASE-T onboard Ethernet ports, four USB 3.0 ports at the rear, two USB 2.0 ports behind the front flap, one RS232 serial port, and one DVI video connector.
