Providing high-resolution operator visualization directly at the machine, the Beckhoff CP3916-0000 integrates a multi-finger touch screen with a high-durability glass front. Designed specifically for mounting arm installation, this control panel operates as an extended display interface, allowing operators to interact with host industrial PCs located in remote control cabinets. By incorporating specialized DVI-E and USB-E 2.0 transmission standards, it maintains signal integrity over substantial distances without requiring active repeater hardware at the display unit. The robust IP65-rated housing provides full dust and liquid ingress protection, making it highly suited for demanding industrial environments.
| Specification Parameter | Technical Value |
|---|---|
| Manufacturer | Beckhoff |
| Model Number | CP3916-0000 |
| Display Size | 15.6-inch widescreen |
| Physical Resolution | 1366 x 768 pixels |
| Touch Screen Type | Multi-finger capacitive touch screen |
| Housing Material | Aluminum housing with tempered glass front |
| Protection Rating | IP65 (complete dust protection, water jet resistance) |
| Maximum Connection Distance | Up to 50 m (164 ft) from the host Industrial PC |
| Interface Standards | DVI-E (Extended) and USB-E 2.0 (Extended, 480 Mbit/s) |
| Mounting Thread Pattern | 4 x M6 threaded holes, 100 x 100 mm pitch on connection block |
| Operating Temperature | 0 to 55 degC |
| Power Supply | 24 V DC (+/- 20%) |
| Shipping Weight (Calculated) | 6.0 kg (13.2 lbs) |
| Connector / Terminal | Function / Circuit Assignment |
|---|---|
| DVI-E Connector (IP65) | Digital video input; compatible with standard PC DVI outputs via transmitter module. |
| USB-E 2.0 Connector (IP65) | High-speed USB extension (480 Mbit/s) for touch screen signal and local USB port interfaces. |
| Power Input Terminal | 24 V DC main supply input; requires clean, filtered industrial power source. |
The CP3916-0000 requires a matching sender unit on the PC side. It is typically paired with Beckhoff CU8801 USB Extended transmitter boxes or PCIe transmitter cards installed directly inside the host Industrial PC. If upgrading from older legacy CP39xx displays, confirm that the existing cable infrastructure matches the high-frequency requirements of DVI-E and USB-E 2.0 to avoid display jitter or touch input disconnects.
When routing DVI-E and USB-E cables over the maximum specified 50-meter run, avoid placing them parallel to high-voltage lines, motor phase leads, or variable frequency drive (VFD) output cables. High electromagnetic interference (EMI) can corrupt high-speed USB-E packet transmissions, resulting in intermittent touch interface calibration losses. Ensure that the mounting arm system is mechanically stable and isolated from structural vibrations that exceed 1g.
Always verify that the 24 V DC power supply at the panel end accounts for voltage drop over long cabling runs. If the supply voltage dips below 19.2 V DC during startup surges, the backlight or touch controller may fail to initialize correctly. Use shielded, low-impedance cables and ground the control panel securely through the mounting arm connection block to the central machine ground.
Global Express Shipping
Returns & Warranty
Manufacturer: BECKHOFF
Product No.: CP3916-0000
Country of origin:Germany
Product Type: Multi-touch Control Panels
Payment: T/T, Western Union
Weight: 500g
Shipping port: Xiamen
Warranty: 12 months
