BECKHOFF CP7919-0000-0000 CP79xx Control Panel

SKU CP7919-0000-0000

In stock
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: BECKHOFF
  • Product No.: CP7919-0000-0000
  • Origin Germany
  • Product Type: Control Panels
  • Payment: T/T, Western Union
  • Weight: 0.5 kg
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

Control Panels CP79xx
Quantity
Call sales Contact

Product Description

Description

The BECKHOFF CP7919-0000-0000 is an Economy Control Panel designed for space-saving mounting arm installation. It features a compact 6.5-inch display that provides clear operator visualization with a resolution of 640 x 480 pixels. This unit is designed to act as an efficient operator interface in diverse industrial environments, housing its components in a durable aluminum enclosure.

Equipped with advanced DVI-E and USB-E 2.0 connection technology, the BECKHOFF CP7919-0000-0000 allows for a physical separation of up to 50 meters between the control panel and the industrial PC. The DVI-E transmission system remains fully compatible with standard DVI output signals from standard PCs, while the USB-E 2.0 interface transmits high-speed USB 2.0 data at up to 480 Mbit/s to support peripheral connections at the operator station.

Features

  • Compact 6.5-inch display with a resolution of 640 x 480 pixels
  • Durable aluminum housing designed for mounting arm installation
  • IP65 protection rating for reliable operation in demanding environments
  • DVI-E and USB-E 2.0 connection technology supporting distances up to 50 meters
  • High-speed USB 2.0 data transmission rate of up to 480 Mbit/s
  • Standard 24 V DC power supply input

Applications

  • Machine-level operation and process monitoring
  • Remote operator terminal installations located away from the main control cabinet
  • Industrial visualization setups requiring mounting arm hardware integration

Technical Specifications

General

Manufacturer BECKHOFF
Exact Model CP7919-0000-0000
Device Type Economy Control Panel

Display and Interface

Display Size 6.5-inch
Resolution 640 x 480 pixels
Interface Technology DVI-E and USB-E 2.0
Maximum Distance Up to 50 meters from PC
USB Transmission Speed Up to 480 Mbit/s

Electrical and Environmental

Power Supply 24 V DC
Operating Temperature 0 to 55 degC
Protection Rating IP65

Mechanical

Housing Material Aluminum
Mounting Method 4 x M6 x 18 mm threaded holes in the backplane

Connections / Interfaces

Interface Function
DVI-E Input Video signal connection from PC
USB-E 2.0 Port High-speed USB 2.0 communication

Installation Guidelines

  1. Verify that the product model BECKHOFF CP7919-0000-0000 matches your system configuration requirements before starting setup.
  2. Ensure the system power is completely de-energized before mounting or executing terminal connections.
  3. Inspect the aluminum housing and IP65-rated connectors for physical integrity prior to mounting.
  4. Secure the unit onto the mounting arm adapter using the four M6 x 18 mm threaded holes on the backplane, applying even torque.
  5. Connect the 24 V DC power supply lines, ensuring correct polarity.
  6. Route the DVI-E and USB-E 2.0 cables securely, taking care to respect the maximum 50-meter cable length limit to prevent signal degradation.
  7. Check the integrity of all IP65 seals and cable entries to maintain environmental protection.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What is the maximum connection distance for the BECKHOFF CP7919-0000-0000?
The BECKHOFF CP7919-0000-0000 can be connected at a distance of up to 50 meters from the industrial PC using DVI-E and USB-E 2.0 connection technology.
What display size and resolution does the BECKHOFF CP7919-0000-0000 have?
The BECKHOFF CP7919-0000-0000 features a 6.5-inch display with a resolution of 640 x 480 pixels.
What is the environmental protection rating of the BECKHOFF CP7919-0000-0000 housing?
The BECKHOFF CP7919-0000-0000 features an aluminum housing with an IP65 protection rating, making it suitable for demanding industrial environments when properly installed.
How is the BECKHOFF CP7919-0000-0000 physically mounted?
The BECKHOFF CP7919-0000-0000 is designed for mounting arm installation using four M6 x 18 mm threaded holes located in the backplane of the enclosure.
What power supply is required for the BECKHOFF CP7919-0000-0000?
The BECKHOFF CP7919-0000-0000 requires a standard 24 V DC electrical power supply to operate.
