The BECKHOFF CX8080 is a compact, DIN-rail-mountable Embedded PC belonging to the CX8000 series. It features an integrated serial interface that supports both RS232 and RS485 communication protocols via a 9-pin D-sub connection. This controller is designed for decentralized automation tasks and can act as a standalone control system or as a protocol gateway in standard industrial networks.
Equipped with an ARM9 32-bit RISC processor running at 400 MHz, the BECKHOFF CX8080 provides a balanced processing platform for PLC tasks. The unit incorporates 64 MB of DDR2 RAM and includes a 512 MB microSD card for system software and user configuration data. Its compact form factor makes it ideal for installation in control cabinets where space is limited.
A key feature of the BECKHOFF CX8080 is its dual I/O bus interface, which automatically detects and supports either EtherCAT Terminals (E-bus) or standard Bus Terminals (K-bus). This auto-recognition capability simplifies commissioning and allows flexible adaptation to various sensor and actuator layouts without manual hardware selection.
| Parameter | Specification |
|---|---|
| Manufacturer | BECKHOFF |
| Model | CX8080 |
| Processor | ARM9, 400 MHz |
| Number of Cores | 1 |
| Main Memory | 64 MB DDR2 RAM (non-expandable) |
| Flash Memory | 512 MB microSD card (expandable) |
| Persistent Memory | 1-second UPS (for 1 MB persistent data) |
| Operating System | Windows Embedded CE 6 |
| Control Software | TwinCAT 2 PLC |
| Interfaces | 1 x RJ45 (10/100 Mbit/s), 1 x USB device, 1 x serial interface (RS232/RS485) |
| Serial Connector | 9-pin D-sub socket |
| Serial Baud Rates | 300 baud to 115 kbaud |
| I/O Connection | E-bus or K-bus (automatic recognition) |
| Current Supply E-bus/K-bus | 2 A |
| Max. Power Consumption | 3 W |
| Dimensions (W x H x D) | 64 mm x 100 mm x 73 mm |
| Operating Temperature | 0 degC to +55 degC |
| Storage Temperature | -25 degC to +85 degC |
| Relative Humidity | 95 %, no condensation |
| Protection Rating | IP20 |
| Interface | Function |
|---|---|
| RJ45 Port | 10/100 Mbit/s Ethernet communication port |
| D-sub (9-pin) | Serial interface configurable for RS232 or RS485 communication |
| USB Device Port | Configuration/maintenance interface located behind the front protection flap |
| Right-side Bus Connector | Connection for E-bus or K-bus I/O terminals (automatic identification) |
When replacing a BECKHOFF CX8080 unit, always record the configuration parameters and back up any target files stored on the microSD card before removing the hardware. Ensure that the replacement unit is running the corresponding TwinCAT 2 runtime environment to maintain application compatibility and communication parameter mapping with external serial systems.
Global Express Shipping
Returns & Warranty
Manufacturer: BECKHOFF
Product No.: CX8080
Country of origin:Germany
Product Type: Embedded PCs
Payment: T/T, Western Union
Weight: 500g
Dimensions: 64 mm x 100 mm x 73 mm
Shipping port: Xiamen
Warranty: 12 months
