BECKHOFF IP2040-B730 Fieldbus Box 8-Channel Digital Output Module

SKU IP2040-B730

In stock

12-month warranty
Free returns within 30 days

Manufacturer: BECKHOFF
Product No.: IP2040-B730
Country of origin:Germany
Product Type: Fieldbus Boxes
Payment: T/T, Western Union
Weight: 2000g
Shipping port: Xiamen
Warranty: 12 months

Description

Designed for decentralized automation tasks in harsh industrial environments, the IP2040-B730 is a rugged fieldbus box featuring 8 digital outputs controlled via the Modbus protocol. This IP67-rated module allows direct connection of actuators to the fieldbus network, significantly reducing control cabinet space requirements and installation complexity. The unit operates on a standard 24 V DC supply and is designed to handle high-current switching demands directly on machinery.

The IP2040-B730 utilizes standardized Ø8 mm snap-in or screw connectors for digital output channels, enabling rapid commissioning and secure signal transmission. By implementing Modbus communications, it integrates seamlessly into existing industrial networks, providing reliable diagnostic and control capabilities at the machine level.

Features

8 independent digital output channels
Modbus RTU protocol communication interface
Robust IP67 protection rating for cabinet-free installation
High current capacity of up to 2 A per output channel
High total aggregate sum current of 12 A
Standardized Ø8 mm connector interface for I/O signals
Compact, vibration-resistant housing designed for direct machine mounting

Applications

Decentralized factory automation and assembly lines
Material handling systems and conveyor controls
Machine tool manufacturing and metalworking machinery
Packaging machinery and processing plants
Environments requiring high moisture and dust protection

Technical Specifications

Manufacturer	BECKHOFF
Model/Part Number	IP2040-B730
Product Type	Fieldbus Box Digital Output Module
Number of Channels	8 digital outputs
Fieldbus Interface	Modbus RTU
Nominal Supply Voltage	24 V DC
Max. Output Current	2 A per channel (Sum current max. 12 A)
Connection Type	Ø8 mm (M8) snap-in/screw connectors
IP Protection Class	IP67 (when all ports are mated or capped)
Operating Temperature	0 to +55 degC
Storage Temperature	-25 to +85 degC
Shipping Weight	2.0 kg

Installation Guidelines

The module is designed to be mounted directly onto machinery or mounting plates without a protective enclosure. For optimal performance and safety, adhere to the following installation practices:

Ensure the mounting surface is flat and clean to prevent mechanical stress on the module housing.
Connect the module's ground terminal to the machine frame using a low-impedance connection to prevent electromagnetic interference (EMI).
Tighten all M8/Ø8 connectors to the recommended torque specifications to maintain the IP67 seal.
Use protective caps on all unused ports to prevent moisture and particulate ingress.
Route fieldbus (Modbus) cables and signal lines away from high-power motor lines or variable frequency drive cables.

Compliance and Certifications

CE
UL

FAQ

What is the primary function of the Beckhoff IP2040-B730?

The IP2040-B730 is an IP67-rated decentralized fieldbus box that provides 8 digital outputs (24 V DC) over a Modbus communication network.

What is the maximum current capacity per output channel on the IP2040-B730?

Each digital output channel can support a load current of up to 2 A, with a total cumulative sum current of 12 A across all 8 channels.

What connection style is used for the I/O signals on this module?

The module uses standard Ø8 mm (M8) snap-in or screw connectors for securing signal and actuator connections.

Does this module require a control cabinet for installation?

No, because the IP2040-B730 features an IP67-rated enclosure, it is designed to be mounted directly on the machine frame in harsh, dusty, or wet environments.
