IP2320-B200

BECKHOFF

BECKHOFF IP2320-B200 Lightbus Fieldbus Box

SKU IP2320-B200

In stock
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: BECKHOFF
  • Product No.: IP2320-B200
  • Origin Germany
  • Product Type: Fieldbus Boxes
  • Payment: T/T, Western Union
  • Weight: 2.0 kg
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

Fieldbus Boxes Lightbus
Quantity
Call sales Contact

Product Description

Description

Designed for distributed industrial automation architectures, the IP2320-B200 provides a robust digital interface designed to mount directly on machinery without requiring an enclosure. This ruggedized fieldbus box interfaces directly with Beckhoff Lightbus networks, offering high-speed fiber optic data transmission immune to electromagnetic interference.

The unit features four digital inputs with a integrated 3 ms hardware filter to eliminate signal bounce, paired with four digital outputs designed for switching high-current loads up to 2 A per channel. Standard M8 circular connectors facilitate fast, secure sensor and actuator connections under harsh operating conditions.

Features

  • Direct integration with Beckhoff Lightbus optical fiber network configurations.
  • Four digital inputs (24 V DC) featuring 3 ms input filters for noise suppression.
  • Four high-current digital outputs (24 V DC) delivering up to 2 A per channel.
  • M8 circular screw-lock connectors for secure industrial cabling.
  • IP67-rated enclosure, providing complete protection against dust and temporary water immersion.
  • Diagnostic LEDs for status monitoring of inputs, outputs, network traffic, and local power supply.

Applications

  • Packaging machinery and material handling conveyors.
  • De-centralized control systems in high-EMI environments.
  • Pneumatic valve manifold control and actuator switching.
  • Automotive assembly lines requiring localized high-current digital I/O.

Technical Specifications

Manufacturer BECKHOFF
Part Number / Model IP2320-B200
Protocol / Interface Lightbus (Optical Fiber)
Number of Inputs 4
Input Voltage 24 V DC (-15% / +20%)
Input Filter Time 3 ms
Number of Outputs 4
Output Voltage 24 V DC
Max. Output Current 2 A per channel (short-circuit protected)
I/O Connection Type M8 circular connector, screw-lock
Protection Class IP67
Operating Temperature 0 to 55 degC
Storage Temperature -25 to 85 degC
Shipping Weight 2.0 kg

Connections and Interfaces

M8 Connector Pin Input Channel Function Output Channel Function
Pin 1 +24 V DC Sensor Supply No Connection (N.C.)
Pin 3 GND Sensor Supply GND Actuator Supply
Pin 4 Input Signal Output Signal (2 A max)

Installation Guidelines

  • Mounting: Secure the unit to a flat surface using the integrated mounting holes. Ensure proper alignment to avoid strain on the optical fibers.
  • Optical Fiber Handling: Maintain the specified minimum bending radius for Lightbus optical fibers to prevent attenuation or physical fiber damage.
  • M8 Connector Torque: Tighten all M8 circular connectors to the recommended torque specification (typically 0.4 Nm) to ensure the IP67 protective seal.
  • Grounding: Connect the functional ground lug on the chassis directly to the machine frame or system ground plane to ensure electromagnetic compatibility.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What is the maximum current output per channel for the Beckhoff IP2320-B200?
The IP2320-B200 supports high-current switching up to 2 A per digital output channel, making it suitable for driving solenoid valves, contactors, and high-load actuators.
Which communication interface does this fieldbus box use?
This module uses the Beckhoff Lightbus system, a fast fiber optic ring protocol that offers complete noise immunity in industrial environments.
Does the IP2320-B200 require a protective cabinet for operation?
No, the module features an IP67 rating, which protects it against dust and water immersion, allowing for direct mounting on machines without an enclosure.
