KL6581

BECKHOFF

BECKHOFF KL6581 Bus Terminal

SKU KL6581

In stock
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: BECKHOFF
  • Product No.: KL6581
  • Origin Germany
  • Product Type: Bus Terminals
  • Payment: T/T, Western Union
  • Weight: 0.085 kg
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

Bus Terminals
Quantity
Call sales Contact

Product Description

Description

The BECKHOFF KL6581 is a K-bus Bus Terminal that serves as an EnOcean master interface. It is designed to enable wireless communication with EnOcean-compatible sensors and actuators in building automation and industrial control environments. The terminal itself does not contain high-frequency transmitter or receiver hardware; instead, it acts as a central controller and interface module that connects to external transceivers.

To achieve wide radio coverage across a building, the BECKHOFF KL6581 supports the connection of up to eight external BECKHOFF KL6583 EnOcean transmitter and receiver modules. This distributed architecture allows physical transceivers to be positioned at optimal locations away from the control cabinet, overcoming distance limitations and avoiding building structure interference.

Features

  • EnOcean master interface terminal for K-bus systems
  • Supports connection of up to eight KL6583 EnOcean transceiver modules
  • Internal data transfer rate of 125 kbaud between the master terminal and transceivers
  • Enables extended physical network layout with up to 500 meters of total connection cable length
  • Power supply provided directly via the K-bus connection
  • Compact housing design suitable for standard DIN rail mounting

Applications

  • Building automation systems requiring wireless EnOcean sensor integration
  • Industrial remote monitoring where physical wiring is impractical
  • Retrofitting existing machinery or facilities with wireless controls

Technical Specifications

General

Parameter Specification
Manufacturer BECKHOFF
Exact Model KL6581
Product Type Bus Terminal (EnOcean Master)
Operating Temperature 0 degC to +55 degC
Storage Temperature -25 degC to +85 degC
Relative Humidity 95%, no condensation
Protection Rating IP20
Weight approx. 85 g
Approvals CE, UL

Electrical and Interface

Parameter Specification
Nominal Voltage 24 V DC (-15% / +20%)
Current Consumption (K-bus) typ. 60 mA
Current Consumption (Power Contacts) typ. 20 mA + load
Data Transfer Rate 125 kbaud
Max. Cable Length 500 m (to KL6583 modules)
Connection Method 2 x 2-wires directly to KL6583 modules
Supported Sub-Modules Up to 8 x KL6583 EnOcean transmitter/receiver modules

Installation Guidelines

  1. Ensure all system power is switched off before mounting or removing the terminal.
  2. Mount the BECKHOFF KL6581 onto a standard 35 mm DIN rail. Ensure it snaps securely into place.
  3. Connect the K-bus power contacts and check that connection pins are correctly aligned with neighboring terminals.
  4. Route the connection cables to the external KL6583 EnOcean transceiver modules, ensuring a maximum length of 500 meters is not exceeded.
  5. Perform a visual inspection of the wiring before applying the 24 V DC power supply to the system.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What is the primary function of the BECKHOFF KL6581 Bus Terminal?
The BECKHOFF KL6581 serves as an EnOcean master terminal, interfacing the Beckhoff Bus Terminal system (K-bus) with up to eight external KL6583 transceiver modules for wireless communication.
Does the BECKHOFF KL6581 have an integrated wireless radio?
No, the BECKHOFF KL6581 does not contain built-in radio components. It requires external KL6583 EnOcean transceiver modules to send and receive wireless signals.
What is the maximum distance allowed between the BECKHOFF KL6581 and its transceiver modules?
The BECKHOFF KL6581 supports a total connection cable length of up to 500 meters to the external KL6583 modules.
What is the K-bus current consumption of the BECKHOFF KL6581?
The BECKHOFF KL6581 has a typical current consumption of 60 mA from the K-bus.
