Manufacturer: Bently Nevada
Product No.: 31000-00-00-00-082-03-02
Country of origin:United States
Product Type: English Proximity Probe Housing Assemblies
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 1200g
Dimensions: 30.02cm x 12cm x 9.14cm
Shipping port: Xiamen
Warranty: 12 months
The 31000-00-00-00-082-03-02 is a professional-grade proximity probe housing assembly from Bently Nevada, specifically configured for machinery vibration and position monitoring applications. This unit serves as a robust protective enclosure for proximity probes, facilitating external access for gap adjustments or probe replacement without requiring machine disassembly. This configuration includes Option 00 for probe and cable (not installed), Option 082 for an 82 mm probe penetration, Option 03 for fittings (two plugs, one M20 fitting), and Option 02 for 3/4-14 NPT mounting threads.
Constructed from high-strength polyphenylene sulfide (PPS) and corrosion-resistant stainless steel, this housing assembly provides superior environmental protection. It complies with API 670 standards for externally mounted proximity probe housings and is suitable for use in demanding industrial environments, including oil and gas, petrochemical, and power generation facilities.
| Option | Code on This SKU | Description |
|---|---|---|
| Orderable Part Number | 31000-00-00-00-082-03-02 | Proximity Probe Housing Assembly |
| A - Probe with Connector | 00 | Probe not required |
| B - Probe Cable Length | 00 | Probe cable not required |
| C - Standoff Adapter Length | 00 | No standoff adapter |
| D - Probe Penetration | 082 | 82 mm penetration |
| E - Fittings | 03 | Two plugs, one M20 fitting |
| F - Mounting Thread | 02 | 3/4-14 NPT |
| Parameter | Specification |
|---|---|
| Manufacturer | Bently Nevada (Baker Hughes) |
| Part Number | 31000-00-00-00-082-03-02 |
| Housing Material | Polyphenylene sulfide (PPS), Stainless steel |
| Mounting Thread | 3/4-14 NPT |
| Fittings | Two plugs, one M20 fitting |
| Probe Penetration | 82 mm |
| Standard Compliance | API 670 |
The 31000 housing assembly should be installed by sliding the outer sleeve into the machine case, followed by the insertion of the probe sleeve to adjust the necessary probe gap. Ensure the housing is securely fitted over the outer sleeve and the retainer is correctly positioned under the retaining nut. For optimal performance, especially in hazardous areas, ensure the unit is installed with an approved transducer system and appropriate I.S. barriers.
