Bently Nevada 330101-00-20-10-10-02-05 3300 XL 8 mm Proximity Probe

SKU 330101-00-20-10-10-02-05

In stock

12-month warranty
Free returns within 30 days

Manufacturer: Bently Nevada
Product No.: 330101-00-20-10-10-02-05
Origin United States
Product Type: 3300 XL 8 mm Proximity Probe
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 0.14 kg
Dimensions: 45 mm x 95 mm x 95 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months

Product Description

Description

330101-00-20-10-10-02-05 is a 3300 XL 8 mm proximity probe featuring a fully threaded 3/8-24 UNF thread body with 0.0 inches of unthreaded length, a 2.0-inch overall case length, a 1.0-meter total cable length, and a standard miniature coaxial ClickLoc connector with CSA, ATEX, and IECEx hazardous area approvals.

This unarmored variant (330101) provides a direct physical contrast to armored alternatives like the 330102 series, which incorporate a stainless steel braid for mechanical wear resistance. The -02 connector option provides a bare miniature coaxial ClickLoc connector, distinguishing it from -01 configurations that include a factory-installed connector protector. Operating on the eddy-current principle, this probe pairs with a 3300 XL Proximitor sensor and an extension cable to form a complete transducer system for non-contact vibration and shaft position measurements in critical rotating machinery.

Features

Unarmored probe configuration designed for standard conduit or protected housing installations.
Fully threaded case (0.0 inches unthreaded length) and 2.0-inch overall case length with 3/8-24 UNF threads.
1.0-meter integrated standard cable length for standard-reach transducer chains.
Miniature coaxial ClickLoc connector (Option 02) without connector protector.
Approved for hazardous areas with CSA, ATEX, and IECEx certification (Option 05).

Applications

This proximity probe is used in machinery protection systems to monitor mechanical parameters on rotating equipment. Typical industrial applications include:

Steam and gas turbine shaft vibration and axial position monitoring.
Compressor and high-speed pump rotor displacement measurements.
Permanent installations in hydrodynamic bearing housings or machine casings.

Ordering Information

Option Segment	Code on This SKU	Description
Orderable Part Number	330101-00-20-10-10-02-05	3300 XL 8 mm Proximity Probe, 3/8-24 UNF thread, without armor
Segment A: Unthreaded Length	00	0.0 in (0 mm) unthreaded length
Segment B: Overall Case Length	20	2.0 in (51 mm) overall case length
Segment C: Total Length	10	1.0 meter (3.3 feet) total length
Segment E: Connector and Cable-Type	02	Miniature coaxial ClickLoc connector, standard cable
Segment F: Agency Approval	05	CSA, ATEX, and IECEx approvals for hazardous areas

Technical Specifications

Manufacturer	Bently Nevada
Part Number	330101-00-20-10-10-02-05
Product Family	3300 XL 8 mm Proximity Transducer System
Measurement Type	Displacement (proximity)
Operating Principle	Eddy current
Probe Tip Diameter	8 mm
Thread Size	3/8-24 UNF
Unthreaded Length	0.0 in (0 mm)
Case Length	2.0 in (51 mm)
Total Length	1.0 meter (3.3 feet)
Connector Type	Miniature coaxial ClickLoc
Armor Option	Without armor
Agency Approvals	CSA, ATEX, IECEx
Dimensions	45 mm x 95 mm x 95 mm (H x W x D)
Weight	0.14 kg

Installation Guidelines

Proper physical installation and electrical connections are required for reliable measurement performance:

Mount the probe with the appropriate probe gap set in accordance with system calibration specifications.
Ensure the probe cable is routed away from high-voltage wiring to minimize electrical noise interference.
Route the cable with appropriate physical shielding and grounding practices standard for vibration monitoring systems.
Avoid twisting or over-torquing the coaxial cable during installation to prevent damage to the inner conductor.

Compliance and Certifications

This transducer component complies with international standards for hazardous area installations when used with compatible certified barriers and Proximitor sensors:

CSA: Certified for use in designated hazardous locations.
ATEX: Certified for explosive atmospheres.
IECEx: Global hazardous area certification scheme.

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

What is the difference between this unarmored probe and the armored version?

The 330101-00-20-10-10-02-05 probe is unarmored, making it ideal for installation within protective conduit. Sibling configurations like the 330102 series feature a stainless steel braided armor over the coaxial cable for direct exposure to abrasive industrial environments.

What does the 02 connector option designate for this specific probe?

The 02 connector option indicates a standard miniature coaxial ClickLoc connector without a connector protector. If you require a silicone connector protector installed at the factory, you would select the 01 option code instead.

Which hazardous area approvals does this 3300 XL proximity probe carry?

This probe configuration is equipped with the 05 agency approval option, which provides hazardous area certifications from CSA, ATEX, and IECEx.

How should the total length of this probe be matched in a transducer system?

This probe features a 1.0-meter total length (Option 10). To maintain the required 5.0-meter or 9.0-meter calibration of the 3300 XL system, it must be paired with a compatible 3300 XL extension cable and Proximitor sensor of matching electrical system length.
