The Bently Nevada 330101-00-67-20-02-05 is a high-performance 8 mm proximity probe designed for continuous, non-contact shaft displacement and vibration measurement in critical industrial machinery. This specific configuration is distinguished by having a completely threaded 6.7-inch (170 mm) case with no unthreaded portion (0.0-inch unthreaded length), an overall probe length of 2.0 meters (6.6 feet), a miniature coaxial ClickLoc connector without a connector protector, and full ATEX, IECEx, and CSA agency approvals for hazardous environments. Utilizing eddy-current technology, it provides high-precision distance monitoring of steam and gas turbines, centrifugal compressors, and heavy industrial pumps.
As an essential component of the Bently Nevada 3300 XL 8 mm Proximity Transducer System, the probe is fully compatible with the 330180 series Proximitor sensors and 330130 standard extension cables. The integrated 2.0-meter standard coaxial cable is insulated with fluoroethylene propylene (FEP) to survive extreme operating conditions. By capturing dynamic shaft clearances, this probe delivers vital vibration diagnostics directly to machine protection systems such as the Bently Nevada 3500 series rack, preventing catastrophic failures and reducing unplanned downtime.
| Option Segment | Code on This SKU | Meaning / Specification |
|---|---|---|
| Orderable Part Number | 330101-00-67-20-02-05 | 3300 XL 8 mm proximity probe, 3/8-24 UNF thread, without armor |
| A - Unthreaded Length | 00 | 0.0 in (0 mm) unthreaded length |
| B - Overall Case Length | 67 | 6.7 in (170 mm) case length (in 0.1 in increments) |
| C - Total Length | 20 | 2.0 meters (6.6 feet) total probe length |
| D - Connector and Cable Option | 02 | Miniature coaxial ClickLoc connector, standard cable |
| E - Agency Approval Option | 05 | CSA, ATEX, IECEx approvals for hazardous environments |
| Manufacturer | Bently Nevada |
| Part Number / Model | 330101-00-67-20-02-05 |
| Product Family | 3300 XL 8 mm Proximity Transducer System |
| Probe Diameter | 8 mm |
| Measurement Type | Displacement (proximity) |
| Operating Principle | Eddy current |
| Nominal Probe DC Resistance | 7.88 ohm +/- 0.50 ohm (center conductor to outer conductor) |
| Probe Tip Material | Polyphenylene sulfide (PPS) |
| Probe Case Material | AISI 303 or 304 stainless steel (SST) |
| Cable Material | 75 ohm triaxial, FEP insulated probe cable |
| Maximum Rated Case Torque | 33.9 N-m (300 in-lbf) |
| Connector Type | Gold-plated miniature male coaxial ClickLoc connector |
| Maximum Connector Torque | 0.565 N-m (5 in-lbf) |
| Operating and Storage Temperature | -52 degC to +177 degC (-62 degF to +350 degF) |
| Humidity Limits | Less than 3 percent change in ASF at 93 percent relative humidity |
| Dimensions | 45 mm x 95 mm x 95 mm (H x W x D) |
| Weight | 0.14 kg |
| Interface Component | Specification / Function |
|---|---|
| Connector Type | Miniature male coaxial ClickLoc connector (gold-plated brass or beryllium copper) |
| Cable Type | 75 ohm standard FEP coaxial cable |
| Recommended Connection | Finger-tight secure connection with 3300 XL extension cable |
Ensure proper installation for accurate machinery protection:
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330101-00-67-20-02-05
Country of origin:United States
Product Type: 3300 XL 8 mm Proximity Probe
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 140g
Dimensions: 45 mm x 95 mm x 95 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
