The 330101-30-49-10-02-05 is a 3300 XL 8 mm proximity probe configuration featuring a 3.0-inch unthreaded length (Option 30), 4.9-inch case length (Option 49), and a 1.0-meter total system length (Option 10). This non-contact eddy-current transducer is designed for 3300 XL monitoring chains, providing precise shaft vibration and axial position measurements in critical rotating machinery applications.
This variant includes a standard miniature coaxial ClickLoc connector (Option 02) and is certified for hazardous area environments with CSA, ATEX, and IECEx approvals (Option 05). The 3300 XL 8 mm system is fully compatible with standard 3300 XL Proximitor sensors and extension cables, maintaining the industry-standard sensitivity of 7.87 V/mm (200 mV/mil) for reliable performance in oil, gas, and power generation environments.
| Orderable Part Number | 330101-30-49-10-02-05 | 3300 XL 8 mm Proximity Probe |
| A - Unthreaded Length | 30 | 3.0 in |
| B - Case Length | 49 | 4.9 in |
| C - Total Length | 10 | 1.0 m |
| D - Connector/Cable | 02 | Miniature coaxial ClickLoc connector, standard cable |
| E - Agency Approval | 05 | CSA, ATEX, IECEx Approvals |
| Manufacturer | Bently Nevada (Baker Hughes) |
| Part Number | 330101-30-49-10-02-05 |
| Probe Diameter | 8 mm |
| Thread Size | 3/8-24 UNF |
| Total Length | 1.0 m |
| Connector Type | Miniature coaxial ClickLoc |
| Sensitivity | 7.87 V/mm (200 mV/mil) |
| Agency Approvals | CSA, ATEX, IECEx |
Ensure the probe is installed using the appropriate threaded mounting bracket. Maintain the recommended probe gap as specified by the machinery monitoring configuration. For hazardous area installations, ensure the entire transducer chain (probe, extension cable, and Proximitor sensor) is installed in accordance with the relevant local and international explosion-protection standards.
This product meets CSA, ATEX, and IECEx requirements for hazardous area operation as specified by Option 05. Ensure site-specific installation complies with the Approvals Quick Reference Guide (108M1756).
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330101-30-49-10-02-05
Country of origin:United States
Product Type: 3300 XL 8 mm Proximity Probe
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 140g
Dimensions: 45 mm x 95 mm x 95 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
