Option 00 (0.0 in unthreaded) and Option 02 (ClickLoc, no connector protector) specify this 3300 XL 8 mm probe configuration — 330102-00-40-50-02-00. This armored proximity probe features a 4.0-inch case length (Option 40) and a 5.0-meter total length (Option 50), designed without hazardous area approvals (Option 00).
Unlike non-armored siblings (such as the 330101 series) or configurations with connector protectors (Option 01), the 330102 model utilizes flexible AISI 302/304 stainless steel armor with an FEP outer jacket to protect the coaxial cable from physical abrasion and chemical exposure. Additionally, the 5.0-meter length variant is calibrated specifically for 5-meter Proximitor systems, bypassing the need for separate extension cables in short-run installations.
This transducer is primarily used for non-contact shaft vibration and axial position measurements in rotating machinery, including steam turbines, gas turbines, compressors, pumps, and generators. The integrated steel armor is ideal for applications where the routing path exposes the cable to mechanical wear, sharp edges, or environmental contaminants.
| Option / Segment | Code on This SKU | Description |
|---|---|---|
| Orderable Part Number | 330102-00-40-50-02-00 | 3300 XL 8 mm proximity probe, 3/8-24 UNF thread, with armor |
| A - Unthreaded Length Option | 00 | 0.0 in (0 mm) |
| B - Overall Case Length Option | 40 | 4.0 in (101.6 mm) |
| C - Total Length Option | 50 | 5.0 meters (16.4 feet) |
| D - Connector and Cable Option | 02 | Miniature coaxial ClickLoc connector, standard cable |
| E - Agency Approval Option | 00 | Not required |
| Parameter | Specification |
|---|---|
| Manufacturer | Bently Nevada (Baker Hughes) |
| Part Number | 330102-00-40-50-02-00 |
| Probe Tip Material | Polyphenylene sulfide (PPS) |
| Case Material | AISI 303 or 304 stainless steel (SST) |
| Thread Size | 3/8-24 UNF-2A |
| Unthreaded Length | 0.0 in (0 mm) |
| Case Length | 4.0 in (101.6 mm) |
| Total Probe Length | 5.0 m (16.4 ft) |
| Armor Material | Flexible AISI 302 or 304 SST with FEP outer jacket |
| Cable Outside Diameter | 3.68 mm (standard cable), 7.67 mm (with armor) |
| Connector Type | Miniature gold-plated coaxial ClickLoc |
| System Compatability | 5-meter 3300 XL Proximitor systems |
| Operating Temperature (Probe) | -52 to +177 degC (-62 to +350 Fahrenheit) |
| Probe Pressure Limit | Differential pressure seal up to tip rating (Viton O-ring) |
| Nominal DC Resistance | 8.73 ohms (typical for 5.0 m length) |
| Minimum Cable Bend Radius | 25.4 mm (1.0 in) |
| Tensile Strength (Max) | 330 N (75 lbf) probe case to lead |
| Dimensions | 250 mm x 250 mm x 45 mm (H x W x D) (typical coiled package) |
| Weight | 0.65 kg (650 g) |
Ensure that the probe is properly gapped using a voltmeter or specialized gap calibration tool before finalizing the mechanical mounting. Maintain a minimum cable bend radius of 25.4 mm (1.0 in) to protect the internal FEP insulation. When tightening the probe case into the bracket, do not exceed the recommended torque limits. Always route the armored cable away from high-temperature exhaust paths and electrical power cables to mitigate thermal damage and electromagnetic interference.
This series meets the following standards when part of a qualified 3300 XL Transducer system:
