330102-00-50-10-02-05: 3300 XL 8 mm proximity probe with 3/8-24 UNF thread, stainless steel armor, fully threaded 0.0 in unthreaded length (Option 00), 5.0 in overall case length (Option 50), 1.0 m total length (Option 10), and standard ClickLoc coaxial connector (Option 02) with ATEX, IECEx, and CSA approvals (Option 05).
Unlike standard unarmored configurations like the 330101, the 330102 includes protective stainless steel flexible armor, making it suitable for environments with high mechanical stress or abrasion. It is designed to work in conjunction with a 3300 XL Proximitor sensor and standard extension cable to form a complete non-contact eddy-current proximity system.
Typical applications include non-contact shaft vibration, axial position, and speed measurements on major rotating machinery. It is widely used in power generation, chemical processing, oil and gas, and wastewater industries to monitor steam turbines, gas turbines, centrifugal compressors, reciprocating compressors, industrial pumps, and gearboxes.
| Option Segment | Code on This SKU | Description |
|---|---|---|
| Orderable Part Number | 330102-00-50-10-02-05 | 3300 XL 8 mm proximity probe, 3/8-24 UNF thread, with stainless steel armor |
| A - Unthreaded Length | 00 | 0.0 in (0 mm) unthreaded length (fully threaded case) |
| B - Overall Case Length | 50 | 5.0 in (127 mm) overall case length |
| C - Total Length | 10 | 1.0 meter (3.3 feet) total length |
| D - Connector and Cable | 02 | Miniature coaxial ClickLoc connector, standard cable |
| E - Agency Approval | 05 | CSA, ATEX, IECEx Approvals |
| Manufacturer | Bently Nevada (Baker Hughes) |
| Part Number / SKU | 330102-00-50-10-02-05 |
| System Series | 3300 XL 8 mm Proximity Transducer System |
| Thread Size | 3/8-24 UNF-2A |
| Armor Material | Stainless steel flexible armor |
| Probe Tip Diameter | 8.0 mm (0.31 in) |
| Unthreaded Length | 0.0 in (0 mm) |
| Overall Case Length | 5.0 in (127 mm) |
| Total Length | 1.0 meter (3.3 feet) |
| Connector Type | Miniature coaxial ClickLoc |
| Operating Temperature | -52 degC to +177 degC (-62 degF to +350 degF) |
| Target Material Compatibility | AISI 4140 steel (standard) |
| Nominal DC Resistance | 7.59 ohms +/- 0.50 ohms (center to outer conductor) |
| Dimensions | 150 mm x 150 mm x 25 mm (H x W x D) |
| Weight | 0.25 kg |
| Interface Element | Details |
|---|---|
| Connector Type | Miniature male coaxial ClickLoc connector |
| Center Conductor | Signal path |
| Outer Conductor | Common shield connection |
Ensure standard mounting practices are observed during probe installation. Tighten the probe body to the recommended torque limits and do not exceed the maximum thread engagement length of 0.563 in (14.3 mm) to avoid binding. Maintain a minimum bend radius of 25.4 mm (1.0 in) for the armored cable sheath. The probe tip must be kept clear of adjacent metal by a minimum side-view clearance diameter of 40 mm (1.6 in) to prevent measurement interference.
| Standard / Approval | Classification Detail |
|---|---|
| CSA, ATEX, IECEx (Option 05) | Intrinsically Safe for Class I, Zone 0, Groups A, B, C, D (Ex ia IIC T5...T1 Ga) and non-incendive (Ex nA/ec IIC T5...T1 Gc) when installed per drawings |
| CE / EMC Directive | Compliant with EN 61000-6-2 (Industrial Immunity) and EN 61000-6-4 (Industrial Emissions) |
| RoHS Directive | European Directive 2011/65/EU and China RoHS compliant |
| Functional Safety | SIL 2 (HFT = 0), SIL 3 (HFT = 1) capable |
