Bently Nevada 330102-00-68-05-02-05 3300 XL 8 mm Proximity Probe

Only 7 item(s) left in stock

Manufacturer: Bently Nevada
Product No.: 330102-00-68-05-02-05
Country of origin:United States
Product Type: 3300 XL 8 mm Proximity Probe
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 140g
Dimensions: 45 mm x 95 mm x 95 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months

View full details

Description

The 330102-00-68-05-02-05 is a 3300 XL 8 mm proximity probe featuring an armored cable configuration and a 3/8-24 UNF thread. This unit is designed for use in 3300 XL monitoring chains, providing non-contact eddy-current displacement measurement for shaft vibration and axial position monitoring on critical rotating machinery. The configuration includes 0.0 in unthreaded length (Option 00) and 6.8 in case length (Option 68) with a total system length of 0.5 meters (Option 05). The probe utilizes a Miniature coaxial ClickLoc connector (Option 02) without a connector protector, paired with standard coaxial cabling. It is rated for hazardous area environments with CSA, ATEX, and IECEx approvals (Option 05). This transducer system is fully compatible with 3300 XL Proximitor sensors and extension cables, designed to maintain linear output over the standard range even in harsh industrial conditions requiring mechanical armor protection.

Features

3300 XL 8 mm proximity transducer system component
Armored cable construction for improved mechanical protection in industrial environments
3/8-24 UNF threaded probe body (Option 00, 6.8 in case length)
0.5 meter total system length (Option 05)
Miniature coaxial ClickLoc connector, standard cable (Option 02)
CSA, ATEX, and IECEx hazardous area approvals (Option 05)
Designed for seamless integration with 3300 XL Proximitor sensors and extension cables

Applications

Turbine and compressor shaft vibration monitoring
Rotor axial position measurement
Critical rotating machinery protection
Fluid film bearing monitoring in petrochemical and power generation facilities

Ordering Information

Option	Code on This SKU	Description
Orderable Part Number	330102-00-68-05-02-05	3300 XL 8 mm Proximity Probe, 3/8-24 UNF, Armored
A - Unthreaded Length	00	0.0 in unthreaded length
B - Case Length	68	6.8 in case length
C - Total Length	05	0.5 meter (1.6 feet)
D - Connector/Cable	02	Miniature ClickLoc, standard cable (no connector protector)
E - Agency Approval	05	CSA, ATEX, IECEx Approvals

Technical Specifications

Parameter	Specification
Manufacturer	Bently Nevada
Part Number	330102-00-68-05-02-05
Probe Diameter	8 mm
Thread Size	3/8-24 UNF-2A
Cable Type	Armored
Connector Type	Miniature coaxial ClickLoc
Agency Approvals	CSA, ATEX, IECEx
Temperature Range	-55 Celsius to 177 Celsius
System Compatibility	3300 XL Proximitor, 3300 XL Extension Cable

Installation Guidelines

Ensure the probe is installed in a rigid mount to prevent excessive vibration at the mounting point.
Maintain the specified probe-to-target gap according to the 3300 XL monitoring system calibration.
Install the Proximitor sensor in a protected, dry location, ideally within an IP54-rated housing or better.
Use appropriate Bently Nevada installation drawings for hazardous area wiring and grounding procedures.
Ensure all cable connections are tight and the ClickLoc connector is securely fastened to prevent signal degradation.

Compliance and Certifications

CSA (Canadian Standards Association)
ATEX (Atmospheriques Explosibles)
IECEx (International Electrotechnical Commission Explosive)

Model Number / Title	Condition	Availability	Action
Bently Nevada 330901-00-78-10-02-00 3300 XL NSv Proximity Probe	Original New	In Stock	View Details
Bently Nevada 330104-00-04-10-11-01 3300 XL 8 mm Proximity Probe	Original New	In Stock	View Details
Bently Nevada 330104-00-04-10-02-01 3300 XL 8 mm Proximity Probe	Original New	In Stock	View Details

Key Features:

#Bently Nevada 3300 XL #Proximity Probes

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

What does the -00 code mean for the unthreaded length?

The 00 option indicates 0.0 inches of unthreaded length on the probe body, meaning the threads extend to the base of the probe tip.

Does this probe include a connector protector?

No, the Option 02 indicates a standard Miniature ClickLoc connector without a connector protector.

Is this probe suitable for hazardous areas?

Yes, the Option 05 designation provides CSA, ATEX, and IECEx approvals for use in hazardous environments.

Can I use this 0.5-meter probe with any extension cable?

This probe is part of a calibrated system; it is designed for use with compatible 3300 XL extension cables and the corresponding 0.5-meter system length requirements.
