Bently Nevada 330103-00-13-10-02-05 3300 XL 8 mm Proximity Probe

Description

The 330103-00-13-10-02-05 is a 3300 XL 8 mm proximity probe designed for non-contact vibration and position measurement in critical machinery, featuring an M10 x 1 thread and unarmored cable construction. This probe is a component of the 3300 XL 8 mm Proximity Transducer System, which is used for monitoring shaft radial vibration, axial position, and rotor speed in fluid-film bearing machines, including gas turbines, steam turbines, compressors, and pumps.

This specific configuration, identified by option code 00 (0.0 in unthreaded length) and 13 (1.3 in case length), includes a 1.0 m total system length (option 10) and a Miniature ClickLoc coaxial connector (option 02). It is rated for hazardous area environments with CSA, ATEX, and IECEx approvals (option 05). The probe is engineered for optimal performance when paired with a compatible 3300 XL Proximitor sensor and extension cable, ensuring measurement signal integrity across the entire 3300 XL transducer chain.

Features

• M10 x 1 probe thread for specific metric mounting requirements.
• Unarmored cable construction.
• Miniature ClickLoc coaxial connector (standard cable type).
• 1.0 meter system length, compatible with standard 3300 XL Proximitor sensor systems.
• 0.0 in unthreaded length and 1.3 in case length configuration.
• Hazardous area certified: CSA, ATEX, and IECEx approvals.

Applications

• Turbine and compressor rotor shaft vibration monitoring.
• Axial position (thrust) measurement.
• Rotor speed and phase reference measurement.
• Critical rotating machinery protection in industrial and petrochemical environments.

Ordering Information

Technical Specifications

Installation Guidelines

Ensure the probe is mounted securely using the appropriate bracket to maintain proper gap settings as defined by the machinery monitoring system requirements. Use shielded cable routing techniques to prevent electromagnetic interference. In hazardous areas, ensure installation complies with local safety regulations regarding intrinsically safe apparatus, specifically adhering to the conditions defined by the CSA, ATEX, and IECEx certifications.

Compliance and Certifications

This product is certified for use in hazardous environments. Approvals include CSA (Canadian Standards Association), ATEX (Atmospheres Explosibles), and IECEx (International Electrotechnical Commission System for Certification to Standards Relating to Equipment for Use in Explosive Atmospheres).
