Manufacturer: Bently Nevada
Product No.: 330103-12-25-10-02-00
Country of origin:United States
Product Type: 3300 XL 8 mm Proximity Probe
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 140g
Dimensions: 45 mm x 95 mm x 95 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
Option 12 (1.2 in unthreaded length) and Option 25 (2.5 in case length) define this 330103-12-25-10-02-00 3300 XL 8 mm proximity probe configuration. As a side-exit proximity transducer, this unit is engineered for non-contact eddy-current displacement measurement, serving as a critical component in 3300 XL 8 mm monitoring chains for shaft vibration and axial position measurement.
This probe is designed for seamless integration with the 3300 XL Proximitor sensor and 3300 XL extension cable. The side-exit cable configuration allows for installation in space-constrained machinery environments. This specific orderable configuration includes a 1.0 m lead with a standard miniature ClickLoc connector and requires no specific hazardous area agency approvals (Option 00).
| Option | Code on This SKU | Description |
|---|---|---|
| Orderable Part Number | 330103-12-25-10-02-00 | 3300 XL 8 mm Proximity Probe, side exit |
| A - Unthreaded Length | 12 | 1.2 in |
| B - Case Length | 25 | 2.5 in |
| C - Total Length | 10 | 1.0 m |
| D - Connector/Cable | 02 | Miniature ClickLoc, standard cable |
| E - Agency Approval | 00 | Not required |
| Manufacturer | Bently Nevada |
| Model | 330103-12-25-10-02-00 |
| System Compatibility | 3300 XL 8 mm Proximitor Sensor |
| Probe Diameter | 8 mm |
| Case Material | AISI 303 stainless steel |
| Connector Type | Miniature ClickLoc coaxial |
| Cable Type | 75 Ohm triaxial, fluoroplastic insulated |
| Operating Temperature | -51 degC to +177 degC |
| Storage Temperature | -51 degC to +177 degC |
Ensure the probe is mounted in a rigid bracket to prevent mechanical resonance. Use appropriate thread sealant on the probe threads if required by the installation environment. When connecting the miniature ClickLoc connector, ensure it is tightened to the recommended torque specifications to maintain signal integrity. Verify that cable routing avoids high-voltage power lines to minimize electromagnetic interference.
This configuration (Option 00) does not carry hazardous area agency approvals. Ensure usage is compliant with local installation codes and safety requirements for non-hazardous environments.
