Manufacturer: Bently Nevada
Product No.: 330104-00-05-05-02-CN
Country of origin:United States
Product Type: 3300 XL 8 mm Proximity Probe
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 140g
Dimensions: 45 mm x 95 mm x 95 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
The 330104-00-05-05-02-CN is an 8 mm reverse mount proximity probe from the 3300 XL transducer system series. This specific configuration features a 0.0 in unthreaded length (Option 00), 0.5 in case length (Option 05), 0.5 m total system length (Option 05), and a standard Miniature ClickLoc connector (Option 02). The -CN suffix indicates this unit includes the China hazardous area approval package (NEPSI + CCC), ensuring compliance for installations within regulated environments in China.
Designed for use with 3300 XL Proximitor sensors and extension cables, this probe provides non-contact eddy-current displacement measurement, essential for monitoring shaft vibration and axial position on critical rotating machinery. The reverse mount design is specifically configured for applications where the probe is installed through the machine case or a bracket, with the probe tip mounted inside the machine and the connector located externally. This system maintains compatibility with the full 3300 XL signal chain and performance specifications, providing the necessary signal integrity for industrial vibration protection loops.
| Option | Code | Description |
|---|---|---|
| Orderable Part Number | 330104-00-05-05-02-CN | 3300 XL 8 mm Proximity Probe, Reverse Mount |
| A - Unthreaded Length | 00 | 0.0 in |
| B - Case Length | 05 | 0.5 in |
| C - Total Length | 05 | 0.5 m |
| D - Connector/Cable | 02 | Miniature ClickLoc, standard cable |
| Suffix | -CN | China hazardous area approval package (NEPSI + CCC) |
| Parameter | Specification |
|---|---|
| Manufacturer | Bently Nevada |
| Part Number | 330104-00-05-05-02-CN |
| System Type | 3300 XL 8 mm Proximity Transducer |
| Probe Diameter | 8 mm |
| Mounting Style | Reverse Mount |
| Connector Type | Miniature ClickLoc |
| Operating Temperature | -51 degC to +177 degC |
| Linear Range | 2 mm (80 mils) |
| Recommended Gap | 1.27 mm (50 mils) |
| Case Material | AISI 303 or 304 stainless steel |
Ensure the probe is installed in a rigid bracket or casing to prevent vibration interference. Tighten the probe mounting nut carefully to avoid thread damage or stress on the probe body. Maintain proper clearance from other probes to avoid cross-talk interference. In hazardous areas, verify that the installation complies with local site safety requirements and the certifications associated with the -CN suffix.
This unit includes the China hazardous area approval package, featuring NEPSI and CCC certifications. The 3300 XL system is designed to meet international standards for vibration monitoring in industrial environments.
