Bently Nevada 330104-00-06-10-01-00 3300 XL 8 mm Proximity Probe

SKU 330104-00-06-10-01-00

In stock

12-month warranty
Free returns within 30 days

Manufacturer: Bently Nevada
Product No.: 330104-00-06-10-01-00
Country of origin:United States
Product Type: 3300 XL 8 mm Proximity Probe
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 140g
Dimensions: 45 mm x 95 mm x 95 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months

Description

The 330104-00-06-10-01-00 is an 8 mm proximity probe from the 3300 XL series, featuring an M10 x 1 thread and armored construction. This specific configuration includes 0 mm unthreaded length (Option 00), 60 mm case length (Option 06), 1.0 meter total system length (Option 10), and a standard cable with a connector protector and Miniature ClickLoc coaxial connector (Option 01). No agency approvals are included with this part number (Option 00).

Used in 3300 XL 8 mm proximity transducer systems, this probe provides non-contact displacement measurement for critical rotating machinery. The 3300 XL design ensures compatibility with 3300 XL Proximitor sensors and extension cables, delivering accurate shaft vibration and axial position data in industrial environments. The armored cable provides enhanced mechanical protection against abrasion and physical impact in demanding installation areas.

Features

M10 x 1 thread configuration with integrated armor for cable protection
0 mm unthreaded length and 60 mm case length for specific mounting requirements
Miniature ClickLoc coaxial connector with integrated connector protector
1.0 meter total system length
Standard cable assembly
Non-contact eddy-current sensing technology

Applications

Shaft vibration and axial position monitoring for turbines and compressors
Critical machinery protection in power generation, oil and gas, and petrochemical facilities
Rotating equipment where mechanical protection of cabling is required

Ordering Information

Option	Code on This SKU	Description
Orderable Part Number	330104-00-06-10-01-00	3300 XL 8 mm Proximity Probe, M10 x 1, armored
A - Unthreaded Length	00	0 mm
B - Case Length	06	60 mm
C - Total Length	10	1.0 meter (3.3 feet)
D - Connector/Cable	01	Miniature ClickLoc with connector protector, standard cable
E - Agency Approval	00	Not required

Technical Specifications

Parameter	Specification
Manufacturer	Bently Nevada
Model	330104
Probe Diameter	8 mm
Thread Type	M10 x 1
Armored	Yes
Total System Length	1.0 m
Connector Type	Miniature ClickLoc coaxial
Connector Protector	Included
Agency Approval	None

Installation Guidelines

Ensure the probe is gapped correctly according to the system manual for the target material. The M10 x 1 thread should be secured using compatible mounting brackets. Route the armored cable to avoid sharp bends or excessive stress on the connector. Always ensure that the total system length (probe + extension cable) matches the requirements of the 3300 XL Proximitor sensor calibration.

Compliance and Certifications

This unit is supplied without hazardous area agency approvals. Verify site-specific certification requirements before installation in regulated environments.

FAQ

What does the 00 code for unthreaded length mean on this probe?

The 00 code indicates that the unthreaded length of the probe body is 0 mm, meaning the probe is threaded up to the tip.

Does this probe include an armored cable?

Yes, the 330104 model is designed with an armored cable to provide additional mechanical protection for the lead wire.

Can this probe be used with a 5-meter Proximitor sensor?

No, 1-meter probes are designed for use with 1-meter system configurations. Ensure the probe and extension cable lengths combine to match the total system length of your Proximitor sensor.

What is the purpose of the 01 connector option?

The 01 option indicates the probe includes a Miniature ClickLoc coaxial connector equipped with a connector protector to prevent contamination.
