Bently Nevada 330104-00-10-05-01-05 3300 XL 8 mm Proximity Probe

Only 2 item(s) left in stock

Manufacturer: Bently Nevada
Product No.: 330104-00-10-05-01-05
Country of origin:United States
Product Type: 3300 XL 8 mm Proximity Probe
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 140g
Dimensions: 45 mm x 95 mm x 95 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months

View full details

Description

330104-00-10-05-01-05 is a 3300 XL 8 mm proximity probe configuration featuring a 0.0 in unthreaded length (Option 00), 1.0 in case length (Option 10), and a 0.5 m total system length (Option 05). This unit is equipped with a miniature ClickLoc coaxial connector including a connector protector (Option 01) and holds CSA, ATEX, and IECEx approvals (Option 05).

As a core component of the 3300 XL 8 mm proximity transducer system, this probe provides non-contact measurement of shaft vibration and axial position on critical rotating machinery. It is designed for use within monitoring chains that include a matched 3300 XL Proximitor sensor and extension cable. The standard cable configuration (Option 01) supports reliable signal transmission in typical industrial environments. The inclusion of a connector protector helps prevent contamination and potential connection issues during installation and operation.

Features

0.0 in Unthreaded Length (Option 00): Fully threaded probe body design.
1.0 in Case Length (Option 10): Compact mechanical form factor for standard mounting.
0.5 m Total Length (Option 05): Optimized for systems where the Proximitor sensor is located in close proximity to the probe measurement point.
Miniature ClickLoc Connector (Option 01): Includes connector protector to shield against environmental contaminants.
Agency Approval (Option 05): Certified for hazardous area use with CSA, ATEX, and IECEx ratings.

Applications

Turbine and compressor shaft vibration monitoring
Rotor axial position measurement
Critical rotating machinery protection
Fluid film bearing monitoring

Ordering Information

Option	Code on This SKU	Description
Orderable Part Number	330104-00-10-05-01-05	3300 XL 8 mm Proximity Probe
A - Unthreaded Length	00	0.0 in
B - Case Length	10	1.0 in
C - Total Length	05	0.5 meter (1.6 feet)
D - Connector/Cable	01	Miniature ClickLoc connector with connector protector, standard cable
E - Agency Approval	05	CSA, ATEX, IECEx Approvals

Technical Specifications

Parameter	Specification
Manufacturer	Bently Nevada
Product Type	3300 XL 8 mm Proximity Probe
Probe Diameter	8 mm
Mounting Thread	M10 x 1
Connector	Miniature ClickLoc coaxial
Cable Type	Standard
Operating Temperature	-52 degC to +177 degC
Storage Temperature	-52 degC to +177 degC
Agency Approvals	CSA, ATEX, IECEx

Installation Guidelines

Ensure the probe is gapped according to the specific 3300 XL Proximitor sensor calibration requirements.
Use appropriate torque settings for the connector; finger-tight is generally required for the 3300 XL ClickLoc connection.
Maintain at least 1.5 times the nominal thread diameter for thread engagement to avoid binding.
Verify hazardous area installation drawings (141092 for ia; 140979 for nA, ec) to ensure compliance with local regulations.

Compliance and Certifications

CSA: Canadian Standards Association
ATEX: Atmosphere Explosibles
IECEx: International Electrotechnical Commission Explosive

Model Number / Title	Condition	Availability	Action
Bently Nevada 330901-00-78-10-02-00 3300 XL NSv Proximity Probe	Original New	In Stock	View Details
Bently Nevada 330104-00-04-10-11-01 3300 XL 8 mm Proximity Probe	Original New	In Stock	View Details
Bently Nevada 330104-00-04-10-02-01 3300 XL 8 mm Proximity Probe	Original New	In Stock	View Details

Key Features:

#Bently Nevada 3300 XL #Proximity Probes

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

What does the -05 option in the last segment of the part number signify?

The -05 code indicates that the probe is certified for hazardous area use with CSA, ATEX, and IECEx approvals.

Can this 0.5 m probe be used with a 5-meter extension cable?

Yes, the 3300 XL system is designed to work with a total system length of 5 or 9 meters. Ensure your Proximitor sensor is calibrated for the specific total system length being used.

What is the purpose of the connector protector included with the -01 option?

The connector protector helps prevent contamination, moisture, and mechanical damage to the miniature ClickLoc connector during installation and in harsh industrial environments.

Is this probe armored?

No, this specific configuration (330104-00-10-05-01-05) does not include stainless steel armor on the cable.
