330104-02-18-10-01-00 is an eddy-current proximity probe featuring an M10 x 1 threaded body with 20 mm unthreaded length and 180 mm overall case length. This specific configuration includes a 1.0 m total cable length protected by flexible stainless steel armor and is terminated with a miniature ClickLoc coaxial connector equipped with a connector protector. Unlike unarmored or longer probe variants, this short-lead, armored version provides robust mechanical shielding against physical abrasion and environmental hazards in tight physical spaces.
The probe works on the eddy-current principle to measure shaft vibration, axial position, and Keyphasor reference signals. It pairs with a 3300 XL extension cable and Proximitor sensor to complete a 5-meter or 9-meter transducer system. Standard AISI 303 stainless steel serves as the case material, and polyphenylene sulfide (PPS) comprises the probe tip. This unit contains Option 00, indicating no hazardous area agency approvals are required for the installation.
The armored protection on this probe makes it ideal for harsh industrial environments where the sensor lead is exposed to flying debris, routing wear, or accidental impact. Typical applications include fluid-film bearing housing installations, high-vibration steam and gas turbines, centrifugal compressors, and generators. The M10 x 1 metric threads allow direct replacement in international machinery configurations requiring metric mounting taps.
| Option / Segment | Code on This SKU | Description / Meaning |
|---|---|---|
| Orderable Part Number | 330104-02-18-10-01-00 | 3300 XL 8 mm Proximity Probe, M10 x 1 thread, with armor |
| A - Unthreaded Length Option | 02 | 20 mm unthreaded body length |
| B - Overall Case Length Option | 18 | 180 mm overall case length |
| C - Total Length Option | 10 | 1.0 meter (3.3 feet) total length |
| D - Connector & Cable Option | 01 | Miniature coaxial ClickLoc connector with connector protector, standard cable |
| E - Agency Approval Option | 00 | Not required / standard non-hazardous area configuration |
| Manufacturer | Bently Nevada |
| Part Number | 330104-02-18-10-01-00 |
| Product Series | 3300 XL 8 mm Proximity Transducer System |
| Probe Type | Eddy-current proximity probe with flexible armor |
| Thread Size | M10 x 1 metric thread |
| Unthreaded Length | 20 mm |
| Case Length | 180 mm |
| Total Cable Length | 1.0 meter (3.3 feet) |
| Connector Type | Miniature ClickLoc coaxial connector (gold-plated brass/beryllium copper) |
| Connector Protector | Yes (pre-installed, female) |
| Armor Material | Flexible AISI 302 or 304 stainless steel with FEP outer jacket |
| Probe Tip Material | Polyphenylene sulfide (PPS) |
| Probe Case Material | AISI 303 or 304 stainless steel |
| Operating Temperature | -52 degC to +177 degC (-62 degF to +350 degF) |
| Pressure Seal | Viton O-ring differential pressure seal between tip and case |
| Linear Range | 2.0 mm (80 mils), nominal |
| Average Scale Factor | 7.87 V/mm (200 mV/mil), nominal |
| System Compatibility | Pairs with 3300 XL extension cable and Proximitor sensor |
| Minimum Bend Radius | 25.4 mm (1.0 in) |
| Tensile Strength | 330 N (75 lbf) probe case to probe lead, max |
| Dimensions (H x W x D) | 10 mm x 10 mm x 180 mm (H x W x D) |
| Weight | 0.35 kg |
Proper gapping is critical to prevent target contact and optimize linear measurement range. Ensure the probe is mounted rigidly in a bracket or threaded housing. Always observe the minimum cable bend radius of 25.4 mm (1.0 in) during routing to prevent internal conductor damage. Hand-tighten the gold ClickLoc connectors until they 'click' to establish a secure electrical connection. For the M10 x 1 threaded case, do not exceed the maximum rated installation torque of 22.6 N-m (200 in-lb).
