Option 03 (30 mm unthreaded length), Option 12 (120 mm overall case length), and Option 05 (0.5 meter total length) specify this metric 3300 XL 8 mm proximity probe configuration — 330104-03-12-05-02-05. This eddy-current proximity probe features M10 x 1 threads, integrated stainless steel armor (Model 330104), and a ClickLoc coaxial connector.
This configuration differs from non-armored siblings (such as the 330103) by incorporating a protective stainless steel armor sleeve over the coaxial cable to resist abrasion, cutting, and mechanical wear. In contrast to standard 1.0-meter or 5.0-meter configurations, the 0.5-meter total length matches shorter routing clearances or direct connection points, and Option 02 provides a standard ClickLoc miniature coaxial connector without an outer connector protector sleeve.
Typically used for radial vibration, axial position, and speed measurements on rotating machinery. Suitable applications include power generation, petrochemical, and oil and gas industries, specifically on turbine shafts, compressors, gearboxes, and large industrial pumps requiring armored mechanical cabling.
| Option / Segment | Code on This SKU | Description / Meaning |
|---|---|---|
| Orderable Part Number | 330104-03-12-05-02-05 | 3300 XL 8 mm Proximity Probe, M10 x 1 thread, with armor |
| A - Unthreaded Length Option | 03 | 30 mm unthreaded length |
| B - Overall Case Length Option | 12 | 120 mm overall case length |
| C - Total Length Option | 05 | 0.5 meter (1.6 feet) total length |
| D - Connector and Cable Option | 02 | Miniature coaxial ClickLoc connector, standard cable |
| E - Agency Approval Option | 05 | CSA, ATEX, IECEx Approvals (Intrinsically Safe) |
| Suffix Option | None | Standard configuration without -CN China-specific approval package |
| Parameter | Specification |
|---|---|
| Manufacturer | Bently Nevada |
| Part Number | 330104-03-12-05-02-05 |
| Probe Tip Diameter | 8.0 mm (0.31 in) |
| Thread Size | M10 x 1 |
| Case Material | Stainless steel |
| Armor Material | Stainless steel flexible armor with FEP outer jacket |
| Unthreaded Length | 30 mm |
| Case Length | 120 mm |
| Total Cable Length | 0.5 meter (1.6 feet) |
| Connector Type | Miniature coaxial ClickLoc male |
| Cable Impedance | 75 ohms |
| Operating Temperature | -52 to +177 degC (-62 to +350 degF) |
| Differential Pressure Seal | Rated up to 7.0 bar (100 psi) across probe tip and case |
| Dimensions | 120 mm x 17 mm x 17 mm (H x W x D) |
| Weight | 0.15 kg |
Maintain proper target alignment and probe-to-target gap (nominally 1.27 mm or 50 mils). Ensure the maximum thread engagement does not exceed 15 mm for the M10 x 1 threads to avoid binding during installation. Connectors must be kept clean and dry, tightened only finger-tight. Observe a minimum bend radius of 25 mm for the armored section of the coaxial cable during routing.
Certified for hazardous environments under Option 05:
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330104-03-12-05-02-05
Country of origin:United States
Product Type: 3300 XL 8 mm Proximity Probe
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 150g
Dimensions: 120 mm x 17 mm x 17 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
