Option 04 (40 mm unthreaded length), Option 10 (100 mm case length), and Option 05 (0.5 m total length) specify this metric Bently Nevada 330104-04-10-05-01-CN 3300 XL 8 mm proximity probe configuration. This proximity probe features a threaded M10 x 1 metric housing and is wrapped in robust, flexible stainless steel armor that shields the 75-ohm triaxial cable from physical degradation in harsh operating environments. Complete with the -CN trailing suffix, this configuration includes the integrated China hazardous area approval package, certifying compliance under NEPSI and CCC regulations for installation in explosive and dust-prone industrial zones.
Used as part of a complete non-contacting machinery protection chain, this 3300 XL 8 mm probe works in tandem with standard extension cables and Proximitor sensors to deliver linear voltage changes proportional to shaft displacement. The shorter 0.5-meter overall probe length is optimized to connect outside the machine housing, reducing internal lead clutter and simplifying cable management. The integrated ClickLoc connector with connector protector (Option 01) safeguards the junction point from moisture and contaminant intrusion.
This proximity probe is used for shaft vibration, axial position, and speed measurements on rotating machinery. Typical environments include power generation steam turbines, petrochemical centrifugal compressors, industrial gas turbines, pumps, and fans operating in regions requiring local hazardous approvals.
| Option / Segment | Code on This SKU | Description |
|---|---|---|
| Orderable Part Number | 330104-04-10-05-01-CN | 3300 XL 8 mm proximity probe, M10 x 1 thread, with armor |
| A - Unthreaded Length Option | 04 | 40 mm unthreaded length (ordered in increments of 10 mm) |
| B - Overall Case Length Option | 10 | 100 mm overall case length (ordered in increments of 10 mm) |
| C - Total Length Option | 05 | 0.5 meter (1.6 feet) total length |
| D - Connector and Cable-Type Option | 01 | Miniature coaxial ClickLoc connector with connector protector, standard armored cable |
| Suffix -CN | -CN | China hazardous area approval package (NEPSI + CCC + applicable markings) |
| Manufacturer | Bently Nevada (Baker Hughes) |
| Part Number / Model | 330104-04-10-05-01-CN |
| Product Series | 3300 XL 8 mm Proximity Transducer System |
| Thread Type | M10 x 1 metric thread |
| Armor Protection | Stainless steel flexible armor (AISI 302 or 304 SST with FEP outer jacket) |
| Unthreaded Length | 40 mm |
| Case Length | 100 mm |
| Total System Length | 0.5 meter (1.6 feet) |
| Cable Type | 75-ohm triaxial, fluoroethylene propylene (FEP) insulated standard cable |
| Connector Type | Miniature male coaxial ClickLoc with connector protector |
| Probe Tip Material | Polyphenylene sulfide (PPS) |
| Probe Case Material | AISI 303 or 304 stainless steel (SST) |
| Operating Temperature | -52 degC to +177 degC (-62 degF to +350 degF) |
| Probe Pressure Seal | Viton O-ring pressure seal |
| Tensile Strength (Max) | 330 N (75 lbf) probe case to probe lead; 270 N (60 lbf) probe lead to extension cable |
| Minimum Cable Bend Radius | 25.4 mm (1.0 in) |
| Weight | 0.18 kg |
| Dimensions | 150 mm x 150 mm x 30 mm (H x W x D) (packaged) |
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330104-04-10-05-01-CN
Country of origin:United States
Product Type: 3300 XL 8 mm Proximity Probe
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 180g
Dimensions: 150 mm x 150 mm x 30 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
Option 04 (40 mm unthreaded length), Option 10 (100 mm case length), and Option 05 (0.5 m total length) specify this metric Bently Nevada 330104-04-10-05-01-CN 3300 XL 8 mm proximity probe configuration. This proximity probe features a threaded M10 x 1 metric housing and is wrapped in robust, flexible stainless steel armor that shields the 75-ohm triaxial cable from physical degradation in harsh operating environments. Complete with the -CN trailing suffix, this configuration includes the integrated China hazardous area approval package, certifying compliance under NEPSI and CCC regulations for installation in explosive and dust-prone industrial zones.
Used as part of a complete non-contacting machinery protection chain, this 3300 XL 8 mm probe works in tandem with standard extension cables and Proximitor sensors to deliver linear voltage changes proportional to shaft displacement. The shorter 0.5-meter overall probe length is optimized to connect outside the machine housing, reducing internal lead clutter and simplifying cable management. The integrated ClickLoc connector with connector protector (Option 01) safeguards the junction point from moisture and contaminant intrusion.
This proximity probe is used for shaft vibration, axial position, and speed measurements on rotating machinery. Typical environments include power generation steam turbines, petrochemical centrifugal compressors, industrial gas turbines, pumps, and fans operating in regions requiring local hazardous approvals.
| Option / Segment | Code on This SKU | Description |
|---|---|---|
| Orderable Part Number | 330104-04-10-05-01-CN | 3300 XL 8 mm proximity probe, M10 x 1 thread, with armor |
| A - Unthreaded Length Option | 04 | 40 mm unthreaded length (ordered in increments of 10 mm) |
| B - Overall Case Length Option | 10 | 100 mm overall case length (ordered in increments of 10 mm) |
| C - Total Length Option | 05 | 0.5 meter (1.6 feet) total length |
| D - Connector and Cable-Type Option | 01 | Miniature coaxial ClickLoc connector with connector protector, standard armored cable |
| Suffix -CN | -CN | China hazardous area approval package (NEPSI + CCC + applicable markings) |
| Manufacturer | Bently Nevada (Baker Hughes) |
| Part Number / Model | 330104-04-10-05-01-CN |
| Product Series | 3300 XL 8 mm Proximity Transducer System |
| Thread Type | M10 x 1 metric thread |
| Armor Protection | Stainless steel flexible armor (AISI 302 or 304 SST with FEP outer jacket) |
| Unthreaded Length | 40 mm |
| Case Length | 100 mm |
| Total System Length | 0.5 meter (1.6 feet) |
| Cable Type | 75-ohm triaxial, fluoroethylene propylene (FEP) insulated standard cable |
| Connector Type | Miniature male coaxial ClickLoc with connector protector |
| Probe Tip Material | Polyphenylene sulfide (PPS) |
| Probe Case Material | AISI 303 or 304 stainless steel (SST) |
| Operating Temperature | -52 degC to +177 degC (-62 degF to +350 degF) |
| Probe Pressure Seal | Viton O-ring pressure seal |
| Tensile Strength (Max) | 330 N (75 lbf) probe case to probe lead; 270 N (60 lbf) probe lead to extension cable |
| Minimum Cable Bend Radius | 25.4 mm (1.0 in) |
| Weight | 0.18 kg |
| Dimensions | 150 mm x 150 mm x 30 mm (H x W x D) (packaged) |
