330500-05-01: Bently Nevada Velomitor piezo-velocity sensor configured with Option 05 mounting thread adaptor (unavailable for standard 330500, directing NPT installations to model 330525) and Option 01 CSA/US/C hazardous area certification.
This specific configuration incorporates a hermetically-sealed 316L stainless steel case housing embedded solid-state electronics, making it immune to mechanical wear and degradation. Unlike moving-parts velocity transducers, this piezo-velocity sensor can be mounted at any orientation angle. The sensor provides an output sensitivity of 3.94 mV/mm/s (100 mV/in/s) to measure absolute structural, casing, or bearing housing vibration in demanding industrial machinery environments.
| Option / Segment | Code on This SKU | Description |
|---|---|---|
| Orderable Part Number | 330500-05-01 | Velomitor Piezo-velocity Sensor |
| A - Mounting Thread Adaptor Option | 05 | Unavailable for 330500 (Note: For 1/4-18 NPT mounting, order 330525). |
| B - Agency Approval Option | 01 | CSA/US/C (Class I, Div 1 Groups A, B, C, D; Class II, Groups E, F, G; Class III). |
| Manufacturer | Bently Nevada |
| Part Number | 330500-05-01 |
| Sensitivity | 3.94 mV/mm/s (100 mV/in/s) plus or minus 5% |
| Frequency Response | 4.5 Hz to 5 kHz (270 cpm to 300 kcpm) plus or minus 3.0 dB; 6.0 Hz to 2.5 kHz (360 cpm to 150 kcpm) plus or minus 0.9 dB |
| Temperature Sensitivity | -14% to +7.5% typical over the operating temperature range |
| Velocity Range | 1270 mm/s (50 in/s) peak |
| Transverse Sensitivity | Less than 5% of sensitivity |
| Amplitude Linearity | plus or minus 2% to 152 mm/s (6 in/s) peak |
| Mounted Resonant Frequency | Greater than 12 kHz |
| Output Bias Voltage | -12 plus or minus 3.0 VDC over temperature referenced to Pin A |
| Dynamic Output Impedance | Less than 2400 ohms |
| Broadband Noise Floor | 0.004 mm/s (160 u in/s) rms, nominal (4.5 Hz to 5 kHz) |
| Grounding | Case isolated |
| Maximum Cable Length | 305 m (1,000 ft) of cable (part number 02173006) with no signal degradation |
| Operating Temperature Range | -55 degC to 121 degC (-67 degF to 250 degF) |
| Shock Survivability | 5,000 g peak, maximum |
| Relative Humidity | To 100% non-submerged (hermetically-sealed case) |
| Base Strain Sensitivity | 0.005 in/s/mstrdin. |
| Magnetic Field Susceptibility | Less than 51 micro-in/s/gauss (50 gauss, 50-60 Hz) |
| Case Material | 316L stainless steel |
| Connector | 2-pin Mil-C-5015 hermetically-sealed, 316L stainless steel shell |
| Mounting Torque | 32-46 kg cm (24-40 in-lb) maximum |
| Polarity | When the sensor case motion is toward the connector, Pin A becomes positive with respect to Pin B |
| Connector Pin | Function |
|---|---|
| Pin A | Signal / Positive Output (referenced for output bias voltage; becomes positive with respect to Pin B when motion is toward connector) |
| Pin B | Common / Return |
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330500-05-01
Country of origin:United States
Product Type: Velomitor Piezo-velocity Sensor
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 142g
Dimensions: 25 mm x 25 mm x 63 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
