Manufacturer: Bently Nevada
Product No.: 330703-000-178-10-02-00
Country of origin:United States
Product Type: 3300 XL 11 mm Proximity Probe
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 180g
Dimensions: 50 mm x 100 mm x 100 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
330703-000-178-10-02-00: 3300 XL 11 mm proximity probe configuration specified with an M14 x 1.5 metric thread, 0 mm unthreaded length (Option 000), 178 mm case length (Option 178), 1.0 m total length (Option 10), and standard cable ending in a miniature coaxial ClickLoc connector (Option 02) without agency approvals (Option 00).
Unlike armored variants (such as the 330704 series) or those equipped with integrated connector protectors (Option 01), this specific configuration features a non-armored design with standard FEP-insulated cabling. It is used in Bently Nevada 3300 XL 11 mm monitoring chains to deliver reliable non-contact eddy-current displacement measurements, providing an extended linear range compared to standard 8 mm systems.
| Option / Segment | Code on This SKU | Description |
|---|---|---|
| Orderable Part Number | 330703-000-178-10-02-00 | 3300 XL 11 mm Probe, M14 x 1.5 thread, without armor |
| A: Unthreaded Length Option | 000 | 0 mm unthreaded length |
| B: Overall Case Length Option | 178 | 178 mm overall case length |
| C: Total Length Option | 10 | 1.0 meter (3.3 feet) total length |
| D: Connector and Cable Option | 02 | Miniature coaxial ClickLoc connector, standard cable |
| E: Agency Approval Option | 00 | Not required |
| Manufacturer | Bently Nevada (Baker Hughes) |
| Part Number | 330703-000-178-10-02-00 |
| System Compatibility | 3300 XL 11 mm Proximity Transducer System |
| Thread Type | M14 x 1.5 metric thread, unarmored |
| Unthreaded Length | 0 mm |
| Case Length | 178 mm |
| Total Probe Length | 1.0 meter (3.3 feet) |
| Linear Range | 4.0 mm (160 mils), starting at approximately 0.5 mm (20 mils) from the target |
| Scale Factor | 3.94 V/mm (100 mV/mil) typical when paired with 3300 XL 11 mm system components |
| Recommended Gap Setting | 2.5 mm (100 mils) |
| Frequency Response | 0 to 8 kHz (+0, -3 dB typical) |
| Probe Tip Material | Polyphenylene sulfide (PPS) |
| Probe Case Material | AISI 304 stainless steel (SST) |
| Cable Construction | 75 ohm triaxial, fluoroethylene propylene (FEP) insulated |
| Connector Material | Gold-plated brass ClickLoc coaxial connector |
| Tensile Strength | 330 N (75 lb) probe case to probe lead maximum |
| Minimum Cable Bend Radius | 25.4 mm (1.0 in) |
| Operating Temperature Range | -52 degC to +177 degC (-62 degF to +351 degF) |
| Pressure Sealing | Designed to seal differential pressure between tip and case (Viton O-ring) |
| Recommended Torque | 21.1 N-m (187 in-lb) standard; 63.3 N-m (560 in-lb) maximum rated |
Ensure the probe cable is routed away from high-voltage sources and sharp edges that could compromise the FEP insulation. Maintain the minimum bend radius of 25.4 mm (1.0 in) for all cable bends. When mounting, do not exceed the recommended installation torque of 21.1 N-m (187 in-lb) to prevent thread binding or mechanical damage to the M14 x 1.5 casing. Verify the probe-to-extension cable connections are clean and finger-tightened, followed by the standard torque procedure if matching specific housing requirements.
The standard 3300 XL 11 mm system is designed to comply with European CE markings for electromagnetic compatibility (RFI/EMI immunity) when properly installed. Since this specific configuration utilizes Option 00 (Agency Approval: Not required), it does not carry specific hazardous area certificates such as ATEX, IECEx, or CSA for explosive environments. Ensure appropriate installation area classifications are reviewed prior to commissioning.
