Option 080 (8.0 meters length), Option 10 (FluidLoc cable), and Option 05 (Multiple Approvals) specify this 330730-080-10-05 3300 XL 11 mm Extension Cable configuration.
This cable provides non-contact eddy-current displacement measurement within 3300 XL 11 mm monitoring chains. It connects a compatible 3300 XL 11 mm proximity probe to a 330780 Proximitor Sensor. The FluidLoc cable construction prevents moisture, oil, and other process fluids from leaking or wicking through the cable jacket, protecting the Proximitor sensor housing in harsh industrial environments. With the multiple approvals option (Option 05), this configuration is certified for use in hazardous areas.
| Option | Code on This SKU | Description |
|---|---|---|
| Orderable Part Number | 330730-080-10-05 | 3300 XL 11 mm Extension Cable |
| A - Cable Length Option | 080 | 8.0 meters (26.2 feet) |
| B - Connector and Cable Option | 10 | FluidLoc cable (unarmored, without connector protector) |
| C - Agency Approval Option | 05 | Multiple Approvals (including ATEX, IECEx, and CSA) |
| Manufacturer | Bently Nevada (a Baker Hughes business) |
| Part Number | 330730-080-10-05 |
| Product Type | 3300 XL 11 mm Extension Cable |
| Cable Length | 8.0 meters (26.2 feet) |
| Cable Impedance | 75 Ohm |
| Cable Type | 75 Ohm triaxial, FEP insulated |
| Cable Construction | FluidLoc (seals against oil and moisture wicking) |
| Armor Option | Unarmored |
| Connector Material | Gold-plated brass |
| Connector Type | ClickLoc coaxial |
| DC Resistance (Core Conductor) | 0.6 +/- 0.2 ohms (8.0 m cable) |
| DC Resistance (Coaxial Conductor) | 2.0 +/- 0.5 ohms (8.0 m cable) |
| Cable Capacitance | 69.9 pF/m (21.3 pF/ft) typical |
| Temperature Range (Operating and Storage) | -52 degC to +177 degC (-62 degF to +351 degF) |
| Relative Humidity | 100% condensing, non-submersible (when connectors are protected) |
| Minimum Bend Radius | 25.4 mm (1.0 in) |
| Maximum Rated Tensile Strength | 270 N (60 pounds) at probe lead to extension cable connectors |
| Connector-to-Connector Torque (Recommended) | Finger tight |
| Connector-to-Connector Torque (Maximum) | 0.565 N-m (5 in-lb) |
| ATEX/IECEx | Ex ia IIC T4/T5 Ga; Ex ia IIIC T90C/T105C Dc; Ex nA IIC T4/T5 Gc; Ex ec IIC T4/T5 Gc |
| CSA/NRTL/C | Class I, Zone 0, AEx/Ex ia IIC T4/T5 Ga; Class I, Groups A, B, C, D; Class II, Groups E, F, G; Class III |
| CE Mark | Compliant with EMC Directive 2014/30/EU; RoHS Directive 2011/65/EU |
| China RoHS | EFUP designation of 15 years in accordance with SJ/T 11364-2024 |
| Functional Safety | SIL 2 (HFT = 0), SIL 3 (HFT = 1) |
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330730-080-10-05
Country of origin:United States
Product Type: 3300 XL 11 mm Extension Cable
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 180g
Dimensions: 50 mm x 100 mm x 100 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
