Bently Nevada 330902-00-12-10-02-05 3300 XL NSv Proximity Probe

Only 7 item(s) left in stock

Manufacturer: Bently Nevada
Product No.: 330902-00-12-10-02-05
Country of origin:United States
Product Type: 3300 NSv Proximity Probes
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 120g
Dimensions: 45 mm x 90 mm x 90 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months

View full details

Description

330902-00-12-10-02-05: 3300 XL NSv proximity probe, 1/4-28 UNF thread with armor (Option 00 unthreaded length, Option 12 case length, Option 10 total length, Option 02 connector, Option 05 agency approval). This 3300 NSv transducer is specifically engineered for applications with limited target area or tight clearance requirements, providing reliable non-contact eddy-current displacement measurement for machinery monitoring.

As part of the 3300 XL NSv Proximity Transducer System, this probe is compatible with the 330980 Proximitor Sensor and 330930 extension cable. The system is designed to maintain consistent scale factors in small-bore machinery and high-speed equipment where standard 3300 XL 8 mm probes are unsuitable due to physical size constraints.

Features

Option 00: 0.0 in unthreaded length
Option 12: 1.2 in case length
Option 10: 1.0 m total system length
Option 02: Miniature coaxial ClickLoc connector with standard cable (armored)
Option 05: Multiple agency approvals (CSA, ATEX, IECEx)
Probe Material: Polyphenylene sulfide (PPS) tip with AISI 304 stainless steel case
Armor: Flexible AISI 302 stainless steel armor for increased mechanical protection

Applications

Aeroderivative turbines
Small-bore rotating machinery
High-speed equipment with limited target geometry
Radial vibration and axial position measurement where clearance is restricted

Ordering Information

Option	Code on This SKU	Description
Orderable Part Number	330902-00-12-10-02-05	3300 NSv Proximity Probe, 1/4-28 UNF, with armor
A - Unthreaded Length	00	0.0 in
B - Case Length	12	1.2 in
C - Total Length	10	1.0 m
D - Connector/Cable	02	Miniature coaxial ClickLoc connector, standard cable
E - Agency Approval	05	Multiple approvals (CSA, ATEX, IECEx)

Technical Specifications

Manufacturer	Bently Nevada
Part Number	330902-00-12-10-02-05
Probe Diameter	1/4-28 UNF-2A
Probe Material	Polyphenylene sulfide (PPS) tip
Case Material	AISI 304 stainless steel (SST)
Cable Type	75 Ohm coaxial, FEP insulated
Connector	Miniature coaxial ClickLoc
System Length	1.0 meter (total)
Agency Approvals	CSA, ATEX, IECEx
Temperature Range (Storage)	-55 degC to +105 degC

Installation Guidelines

Ensure the probe is installed in accordance with Bently Nevada installation drawings for the corresponding hazardous area classification. Proper isolation from the machine housing ground is required, typically achieved using mounting pads for the Proximitor Sensor. Use silicone self-fusing tape to protect connectors from environmental ingress if not using factory-provided connector protectors.

Compliance and Certifications

This product meets the requirements of the 3300 XL NSv system as defined in the datasheet. Approvals include CSA (Class I, Div 2), ATEX, and IECEx for hazardous locations, subject to specific temperature schedules and installation drawings.

Model Number / Title	Condition	Availability	Action
Bently Nevada 330901-00-78-10-02-00 3300 XL NSv Proximity Probe	Original New	In Stock	View Details
Bently Nevada 330104-00-04-10-11-01 3300 XL 8 mm Proximity Probe	Original New	In Stock	View Details
Bently Nevada 330104-00-04-10-02-01 3300 XL 8 mm Proximity Probe	Original New	In Stock	View Details

Key Features:

#Bently Nevada 3300 NSv #Proximity Probes

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

What is the significance of the NSv designation in this probe?

The NSv (Near-field) series is specifically designed for small-bore machinery and tight clearances where a standard 8 mm probe would have an overly large target area, preventing accurate measurements.

Does this SKU include armor for the cable?

Yes, Option 02 indicates the probe includes stainless steel armor for added mechanical protection in the field.

What does Option 05 signify in the orderable code?

Option 05 indicates that the probe is certified with multiple hazardous area approvals, including CSA, ATEX, and IECEx.

Can this probe be used with standard 3300 XL Proximitor sensors?

No, the 330902 NSv probe is intended for use with the 330980 NSv Proximitor Sensor and 330930 extension cable to ensure system performance.
