330902-00-40-10-02-05: 3300 NSv armored proximity probe, featuring a 1/4-28 UNF thread, 0.0 in unthreaded length (Option 00), 4.0 in overall case length (Option 40), 1.0 m total length (Option 10), miniature ClickLoc coaxial connector (Option 02), and Multiple Approvals hazardous area agency certification (Option 05).
This eddy-current proximity probe belongs to the 3300 XL NSv system, which operates in space-constrained industrial machinery where standard 5 mm or 8 mm proximity systems cannot fit. The built-in stainless steel armor acts as a mechanical barrier protecting the 75-ohm coaxial cable from damage caused by physical impact or abrasive environments. This specific configuration pairs with the 3300 XL NSv Proximitor Sensor and appropriate extension cables to measure shaft radial vibration or axial position.
| Option / Segment | Code on This SKU | Description |
|---|---|---|
| Orderable Part Number | 330902-00-40-10-02-05 | 3300 NSv Proximity Probe, 1/4-28 UNF thread, with armor |
| A - Unthreaded Length | 00 | 0.0 in (0 mm) unthreaded length |
| B - Case Length | 40 | 4.0 in (102 mm) overall case length |
| C - Total Length | 10 | 1.0 meter (39 in) total length |
| D - Connector and Cable-Type | 02 | Miniature coaxial ClickLoc connector, standard cable |
| E - Agency Approval | 05 | Multiple Approvals (CSA, ATEX, IECEx) |
| Manufacturer | Bently Nevada |
| Part Number / Model | 330902-00-40-10-02-05 |
| Product Series | 3300 XL NSv Transducer System |
| Thread Type | 1/4-28 UNF-2A |
| Mechanical Armor | Flexible AISI 302 stainless steel armor |
| Unthreaded Length | 0.0 in (0 mm) |
| Overall Case Length | 4.0 in (102 mm) |
| Total Cable Length | 1.0 meter (39 in) |
| Connector Type | Gold-plated brass ClickLoc miniature coaxial connector |
| Probe Tip Material | Polyphenylene sulfide (PPS) |
| Probe Case Material | AISI 304 stainless steel (SST) |
| Cable Impedance | 75 ohms |
| Linear Range | 1.5 mm (60 mils) from approximately 0.25 to 1.75 mm (10 to 70 mils) |
| Recommended Gap | 1.0 mm (40 mils) |
| Incremental Scale Factor (ISF) | 7.87 V/mm (200 mV/mil) |
| Deviation from Best Fit Straight Line (DSL) | Less than +/-0.06 mm (+/-2.3 mils) |
| Tensile Strength (Maximum Rated) | 220 N (50 lb) probe case to lead and armor |
| Operating and Storage Temperature Range | -52 to +177 degC (-62 to +351 degF) |
| Relative Humidity Limit | 100 percent condensing, non-submersible when connectors are protected |
| Standard Calibration Material | AISI 4140 steel |
Proper installation requires clean, dry connector junctions. The miniature coaxial ClickLoc connector requires finger-tight torque (maximum 0.56 Nm or 5 in-lb) during connection. Avoid bending the armored cable below the minimum bend radius of 25.4 mm (1.0 in). Standard installation requires tapping mounting holes with a #3 or larger tap drill for 1/4-28 UNF threads. Do not exceed the maximum case torque limit of 5.1 Nm (45 in-lb) during probe case insertion.
Under Option 05, this probe complies with ATEX, IECEx, and CSA standards for hazardous area installation (Zone 0, 1, and 2, Div 1 and 2), with intrinsic safety parameters meeting Ui = -28V, Ii = 140 mA, Pi = 0.91W when combined with approved barriers and Proximitor sensors.
