Bently Nevada 330909-00-60-10-02-05 3300 NSv Proximity Probe

SKU 330909-00-60-10-02-05

In stock

12-month warranty
Free returns within 30 days

Manufacturer: Bently Nevada
Product No.: 330909-00-60-10-02-05
Origin United States
Product Type: 3300 NSv Proximity Probes
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 0.12 kg
Dimensions: 45 mm x 90 mm x 90 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

Quantity

Call sales Contact

Product Description

Description

Option 00 (0.0 in unthreaded length) and Option 60 (6.0 in overall case length) specify this stainless steel armored 3300 NSv proximity probe configuration — 330909-00-60-10-02-05.

Unlike unarmored versions such as the 330908, the 330909 design integrates protective stainless steel armor over the 1.0-meter coaxial cable to prevent abrasion and mechanical wear in challenging machinery environments. This configuration features a miniature coaxial ClickLoc connector (Option 02) with no connector protector and standard cable, and carries a multiple approvals agency package (Option 05) for installation in hazardous environments. This non-contact eddy-current displacement sensor is designed for tight clearances and reduced target areas where standard-sized probes cannot fit.

Features

Option 00 unthreaded length provides a fully threaded probe casing for compact mounting.
Option 60 provides a 6.0-inch overall case length constructed of robust AISI 304 stainless steel.
Option 10 specifies a 1.0-meter total probe cable length.
Option 02 includes a miniature coaxial ClickLoc connector on standard 75-ohm FEP-insulated cable.
Integrated flexible AISI 302 stainless steel armor provides physical shielding for the cable.
Option 05 agency approval package delivers ATEX, IECEx, and CSA certifications for hazardous zones.
Polyphenylene sulfide (PPS) probe tip ensures excellent chemical resistance and durability.

Applications

Used in small-bore machinery, aeroderivative gas turbines, centrifugal compressors, pumps, and high-speed equipment with limited target geometries. This system is ideal for monitoring radial vibration, axial position, and speed in confined industrial spaces.

Ordering Information

Option / Segment	Code on This SKU	Description
Orderable Part Number	330909-00-60-10-02-05	3300 NSv Proximity Probe, 3/8-24 UNF thread, with armor
A - Unthreaded Length Option	00	0.0 in unthreaded length
B - Overall Case Length Option	60	6.0 in overall case length
C - Total Length Option	10	1.0 meter (39 in) total length
D - Connector and Cable-Type Option	02	Miniature coaxial ClickLoc connector, standard cable
E - Agency Approval Option	05	Multiple Approvals (CSA, ATEX, IECEx intrinsically safe & non-incendive)

Technical Specifications

Manufacturer	Bently Nevada (Baker Hughes)
Part Number	330909-00-60-10-02-05
Thread Size	3/8-24 UNF-2A
Case Material	AISI 304 stainless steel (SST)
Tip Material	Polyphenylene sulfide (PPS)
Cable Armor	Flexible AISI 302 SST uncoated armor
Cable Type	75-ohm coaxial, FEP insulated probe cable
Connector Type	Gold-plated brass ClickLoc miniature male coaxial connector
System Compatibility	3300 XL NSv system (330980 Proximitor, 330930 extension cable)
Linear Range	1.5 mm (60 mils), starting at approximately 0.25 mm (10 mils) from target
Incremental Scale Factor (ISF)	7.87 V/mm (200 mV/mil)
Recommended Gap	1.0 mm (40 mils)
Deviation from Best Fit Straight Line (DSL)	Less than +/-0.06 mm (+/-2.3 mils)
Probe DC Resistance (Center to Outer)	4.2 +/- 0.5 ohms
Power Input Requirements	-17.5 Vdc to -26 Vdc (at 12 mA maximum consumption without barriers)
Frequency Response	0 to 10 kHz: +0, -3 dB
Probe Operating Temperature Range	-55 degC to +177 degC (-67 degF to +351 degF)
Maximum Rated Tensile Strength	220 N (50 lb) case-to-lead

Installation Guidelines

Maintain a minimum 9.5 mm probe-to-probe clearance to prevent electromagnetic cross-talk.
Ensure the recommended minimum counterbore diameter of 13 mm (0.5 in) is applied.
Torque the 3/8-24 thread casing up to a maximum rated torque of 33.9 N m (300 in-lb).
Do not exceed the minimum cable bend radius of 25.4 mm (1.0 in).
Ensure ClickLoc connectors are connected finger-tight during installation.

Compliance and Certifications

Class I, Zone 0: AEx/Ex ia IIC T5...T1 Ga
Class I, Division 2, Groups A, B, C, and D
ATEX/IECEx: Ex ia IIC T5...T1 Ga
ATEX/IECEx: Ex nA IIC T5...T1 Gc
ATEX/IECEx: Ex ec IIC T5...T1 Gc
Functional Safety: SIL 2 (HFT = 0), SIL 3 (HFT = 1)
CE, RoHS Compliant

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

What does the unthreaded length code of 00 mean for the 330909-00-60-10-02-05 probe?

The unthreaded length code of 00 indicates a fully threaded probe case with 0.0 inches of unthreaded length.

What cable protection is included with this specific proximity probe model?

The probe features integrated stainless steel armor over its 1.0-meter coaxial cable to protect it against physical wear and abrasion.

What is the overall case length and thread size of this configuration?

This probe configuration has a 3/8-24 UNF-2A thread size and an overall case length of 6.0 inches.

Does this configuration require a separate connector protector?

No, this specific variant uses option code 02, which features a miniature coaxial ClickLoc connector with standard cable and no connector protector.
