Bently Nevada 84661-15 3300 Series Interconnection Cable

Description

84661-15 is a standard interconnection cable designed for the Bently Nevada 3300 series vibration monitoring systems. This 15 ft (4.5 m) cable serves as the critical link between the transducer and the Proximitor sensor or monitor input. It is constructed as a shielded 0.382 mm2 (22 AWG) cable, ensuring reliable signal integrity in industrial environments while minimizing electrical noise interference.

This configuration features a moisture-resistant female connector on the transducer end and ring lugs on the monitor termination end. The cable is designed for durable performance in harsh machinery monitoring applications, providing a stable, consistent signal path for critical assets like turbines, compressors, and pumps.

Features

• Length: 15 ft (4.5 m) standard configuration
• Cable Type: Shielded 0.382 mm2 (22 AWG)
• Connector (Transducer end): Moisture-resistant female connector
• Termination (Monitor end): Ring lugs
• Operating Temperature: -29 degC to 121 degC (-20 degF to 250 degF)
• Construction: Designed for reliability in machinery protection chains

Applications

• Vibration monitoring of rotating machinery
• Axial position and shaft vibration measurement chains
• Interconnection between proximity probes and monitoring instrumentation
• Petrochemical, power generation, and oil and gas sector machinery protection

Ordering Information

Technical Specifications

Installation Guidelines

Ensure proper cable routing to avoid high-voltage interference and mechanical abrasion. Cables should be secured using appropriate cable clamps or conduit systems. Maintain a minimum bend radius to prevent internal wire damage or connector strain. The moisture-resistant connector should be inspected during installation to ensure a complete seal for long-term reliability in industrial settings.
