Manufacturer: Bently Nevada
Product No.: 84661-40
Country of origin:United States
Product Type: Interconnection Cables
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 60g
Dimensions: 1.8cm x 1.6cm x 123cm
Shipping port: Xiamen
Warranty: 12 months
The 84661-40 is a standard armored interconnect cable designed for Bently Nevada High Temperature Velomitor (HTVS) systems. This specific configuration features a 40-foot (12.2 m) length of shielded 0.382 mm2 (22 AWG) cable protected by stainless steel armor, which provides mechanical protection against abrasion and physical damage in demanding industrial environments.
The cable is equipped with a moisture-resistant female connector at the HTVS transducer end and ring lugs at the monitor end, ensuring reliable signal transmission for vibration monitoring applications. By utilizing this armored cabling, operators can extend the HTVS sensor's reach while maintaining signal integrity in areas where cables are exposed to potential impact, debris, or harsh industrial conditions.
| Option | Code on This SKU | Description |
|---|---|---|
| Orderable Part Number | 84661-40 | Standard Armored Interconnect Cable |
| A - Length | 40 | 40 feet |
| Parameter | Specification |
|---|---|
| Manufacturer | Bently Nevada |
| Part Number | 84661-40 |
| Cable Type | Standard Armored Interconnect Cable |
| Conductor Size | 0.382 mm2 (22 AWG) |
| Shielding | Shielded twisted pair |
| Connector (Sensor End) | Moisture-resistant female connector |
| Termination (Monitor End) | Ring lugs |
| Operating Temperature | -29 C to 121 C (-20 F to 250 F) |
| Armor Material | Stainless steel |
| Minimum Bend Radius | 51 mm (2.0 in) |
Ensure the cable is routed in a way that minimizes exposure to extreme heat sources beyond the specified 121 C limit for the cable. Use appropriate cable clamps and stainless steel ties to secure the armored cable and prevent strain on the connectors. When installing in hazardous areas, ensure the complete monitoring loop (transducer, cable, and monitor) complies with local electrical codes and the specific agency approvals required for the installation site.
