Bently Nevada 84661-60 Standard Armored Interconnect Cable

Description

The 84661-60 is a standard armored interconnect cable designed for use with the 330750 and 330752 High Temperature Velomitor System (HTVS). This specific configuration features a 60 ft (18.3 m) cable length, protected by a durable stainless steel armor jacket over a shielded 0.382 mm2 (22 AWG) cable. It includes a moisture-resistant female connector at the HTVS sensing end and ring lugs at the monitor termination end, providing a reliable signal path in demanding industrial environments. This armored cable is engineered to maintain signal integrity while offering mechanical protection against abrasion and physical damage. The assembly is rated for operation in temperatures ranging from -29 degC to 121 degC (-20 degF to 250 degF), making it suitable for plant floor applications where equipment exposure to environmental hazards is a concern.

Features

• 60 ft (18.3 m) total length (indicated by suffix -60)
• Stainless steel armor for enhanced mechanical protection and abrasion resistance
• Shielded 0.382 mm2 (22 AWG) twisted pair cable to minimize noise interference
• Moisture-resistant female connector for secure HTVS sensor coupling
• Ring lug termination for stable connection at the monitor/junction box
• Compatible with 330750 and 330752 High Temperature Velomitor Systems

Applications

• High-temperature machinery vibration monitoring
• Rotating equipment protection in petrochemical and power generation facilities
• Harsh industrial environments requiring abrasion-resistant cabling
• Signal transmission between HTVS sensors and monitoring instrumentation

Ordering Information

Option	Code on This SKU	Description
Orderable Part Number	84661-60	Standard Armored Interconnect Cable
Length (NN)	60	60 feet (18.3 meters)

Technical Specifications

Manufacturer	Bently Nevada (Baker Hughes)
Part Number	84661-60
Cable Type	Standard Armored Interconnect Cable
Construction	Stainless steel armor over shielded 22 AWG (0.382 mm2) cable
HTVS End Connector	Moisture-resistant female connector
Monitor End Termination	Ring lugs
Operating Temperature	-29 degC to 121 degC (-20 degF to 250 degF)
Application	330750 / 330752 High Temperature Velomitor System

Installation Guidelines

Ensure the cable is routed away from high-voltage power lines to prevent electromagnetic interference. When installing, adhere to the minimum bend radius of 51 mm (2.0 in) to prevent damage to the internal conductors or the armor jacket. Verify all connector seals are clean and moisture-resistant boots (if applicable) are properly seated to maintain the specified ingress protection rating. Secure the cable using appropriate clamps or straps to minimize vibration-induced wear at termination points.
